2.2.4 Call Button and Indicator Light

2.2.4.1 Indicator Light Function
• Upon initial power or reset, the indicator light will illuminate.
• When the software has finished initialization, the indicator light will blink twice.
• When a call is established (not just ringing), the indicator light will blink.
• On the
sets the normal state for the indicator light. The indicator light will still blink during
initialization and calls.
• The indicator light flashes briefly at the beginning of RTFM mode.
2.2.4.2 Dialing from the Keypad
• See the

2.2.5 Network Connectivity, and Data Rate

When you plug in the Ethernet cable or power supply:
• The square, green Link light above the Ethernet port indicates that the network connection has
been established (see
baud rate:
Operations Guide
Device Configuration Page, there is an option called
Figure 2-6. Call Button and Indicator Light
Enable Telephone Operation
Figure 2-7). The Link light changes color to confirm the auto-negotiated
930370I
Installing the VoIP Intercom with Keypad (Flush-Mounted)
Button Lit When
setting in Section 2.3.6, "Configure the Button
Parts List
Idle. This option
Call button and indicator light
Parameters".
