2. On the SIP Configuration page, enter values for the parameters indicated in
Web Page Item
Enable SIP Operation
SIP Settings
SIP Server
Backup SIP Server 1
Backup SIP Server 2
Remote SIP Port*
Local SIP Port*
Outbound Proxy
Outbound Proxy Port
SIP User ID*
Authenticate ID*
Authenticate Password*
Register with a SIP Server*
Re-registration Interval (in seconds)*
Unregister on Reboot*
Operations Guide
Installing the VoIP Intercom with Keypad (Flush-Mounted)
Table 2-10. SIP Configuration Parameters
Description
Enables or disables SIP operation.
Use this field to set the address (in dotted decimal notation
or as a canonical name) of the SIP registrar. This field can
accept canonical names of up to 255 characters in length.
When the primary SIP Server goes offline and the device
fails to register after the normal re-registration interval, the
controller will fall back to using Backup SIP Server 1.
If Backup SIP Server 1 fails, the device will use Backup SIP
Server 2.
If a higher priority SIP Server comes back online, the
device will switch back to this server.
You can leave the Backup SIP Server 1 and Backup SIP
Server 2 fields blank.
Type the Remote SIP Port number (default 5060)
(8 character limit).
Type the Local SIP Port number (default 5060)
(8 character limit).
Type the Outbound Proxy as either a numeric IP address in
dotted decimal notation or the fully qualified host name
(255 character limit [FQDN]).
Type the Outbound Proxy Port number (8 character limit).
Type the SIP User ID (up to 64 alphanumeric characters).
Type the Authenticate ID
(up to 64 alphanumeric characters).
Type the Authenticate Password (up to 64 alphanumeric
characters).
Check this box to enable SIP Registration.
For information about Point-to-Point Configuration, see
Section 2.3.5.1, "Point-to-Point
Type the SIP Registration lease time in minutes (default is
60 minutes) (8 character limit). Re-registration Interval (in
seconds)*
When selected, on boot, the device will first register with a
SIP server with a expiration delay of 0 seconds. This has
the effect of unregistering any current devices on this
extension.
930370I
Parts List
Table 2-10.
Configuration".
