Web Page Item
Call Button
ID
Security Code (0 through 9)
Misc Settings
Play Button Tone
3. After changing the parameters, click the Save button.
Operations Guide
Table 2-11. Button Configuration Parameters (continued)
Description
Enter the desired dial-out extension number (64 character
limit). Security codes are limited to seven characters and
are activated with the # key.
Note: For information about dial-out extension strings and
DTMF tones, see
Strings and DTMF Tones (using
Type the desired Extension ID (64 character limit).
Enter the desired security code number (7 character limit).
When a security code is entered on the keypad that
matches one of the seven-digit fields specified on the
page, the relay will be activated.
Check this box to hear a tone when a keypad button is
pushed. This setting applies to all modes and determines
whether the device will play an audible sound out of the
speaker when doing any of the following:
• Entering a security code
• Initiating a speed dial
• Pressing the keys in cellphone and telephone modes
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
930370I
Installing the VoIP Intercom with Keypad (Flush-Mounted)
Section 2.3.6.1, "Dial Out Extension
Parts List
rfc2833)".
