2.2.6 RTFM Button

When the Intercom is operational and linked to the network, use the Reset Test Function
Management (RTFM) button (see SW1 in
confirm the Intercom's IP Address and test that the audio is working.
Note
2.2.6.1 Announcing the IP Address
To announce a device's current IP address:
1. Press and release the RTFM button (SW1) within a five second window.
Note
Note
Operations Guide
You must do this test prior to final assembly.
The device will use DHCP to obtain the new IP address (DHCP-assigned address or default
to 10.10.10.10 if a DHCP server is not present).
Pressing and holding the RTFM button for longer than five seconds will restore the device
to the factory default settings.
930370I
Installing the VoIP Intercom with Keypad (Flush-Mounted)
Figure 2-8) on the Intercom board to announce and
Figure 2-8. RTFM Button
Parts List
RTFM
