  • Page 1 LEICA V-LUX 40 Instructions...

  • Page 2: Table Of Contents

    Table of contents Before use Basics Before use ..........6 Sequence of operations ...... 25 About GPS ............8 Taking pictures with automatic Scope of Delivery ........9 exposure control [Program AE] mode ......27 Accessories ........... 9 Storing a focus setting ......28 Names and functions of the main components .........
  • Page 3 Table of contents Using the [Setup] menu ...... 54 Recording [Clock Set] ...........54 [Auto Clock Set] ..........54 Changing recording information [World Time] ..........54 display ..........62 [Travel Date] ..........54 Using the zoom ........63 [Beep] ............54 Zooming with touch operation .....64 [Volume] ............55 Zoom modes and their application ....65 [Cust.Set Mem.] ..........55...
  • Page 4 Table of contents Taking 3D pictures ....... 84 Reviewing Registering your own setting combinations [Custom] Mode ... 85 Playing back still pictures recorded using the serial exposure [Cust.Set Mem.] ..........85 function ..........109 [Custom] ............86 Taking picture series ......87 Different playback methods ....111 [2D/3D Settings] ........
  • Page 5 Licence Agreement for on a map ...........146 Place Name and Map Data .......188 Displaying only pictures taken in the Leica service addresses ....195 same area ..........147 Displaying a map by selecting a country or region ............148 Using the map data on the DVD ..149 Installing “LEICA Map Tool”...

  • Page 6: Before Use

    Before use ■ Camera handling Protect the camera against excessive vibration, force, or pressure. ● Avoid using the camera under the following conditions, which may damage the lens, LCD monitor, or camera body. This may also cause the camera to malfunction or prevent recording.
  • Page 7 ■ No compensation for missed shots Leica Camera AG cannot compensate for missed shots if technical problems with the camera or card prevent recording. ■ Carefully observe copyright laws Unauthorized use of recordings which contain works with copyright for purposes other than personal use is prohibited under copyright law.

  • Page 8: About Gps

    Before use About GPS ■ About the camera’s location name information Before using the camera, be sure to read “Licence Agreement for Place Name and Map Data”. (→188) ■ When [GPS Setting] is [ON], the GPS function works even if the camera is turned OFF.

  • Page 9: Scope Of Delivery

    423-106.001-021 ® Photoshop ® Elements ® DVD with Adobe 423-106.001-022 ® ® Premiere Elements DVD with LEICA Map 423-106.001-020 Tool USB cable 423-105.001-010 AV cable 423-106.001-009 Button template for 423-083.001-026 / Canada / Taiwan -027 Short instructions 93 433 - 93 436...

  • Page 10: Names And Functions Of The Main Components

    Names and functions of the main components Mode dial (→25) Use this to select the recording mode. Flash (→66) Built-in GPS antenna (→127) Self-timer indicator (→70) AF Assist Lamp (→103) Lens barrel Lens (→6, 186) Speaker (→55) GPS status indicator Zoom lever (→63) Use to determine the desired focal length /...

  • Page 11: Cursor Buttons

    Names and functions of the main components LCD monitor REC/PLAY switch (→25) Use to select the recording or playback mode. (→55, 62, 170) We recommend using the supplied wrist strap to avoid dropping the camera. [EXPOSURE] / [MAP] button (→73, 145) In recording mode: Use to set shutter speed or aperture values.

  • Page 12: Touch Operations

    Names and functions of the main components Touch operations This camera’s monitor surface senses pressure that is applied to it. Touch Drag To “touch” is to press the monitor’s To “drag” is to touch and slide your finger surface and then pull the finger back across the monitor’s surface.

  • Page 13: Charging The Battery

    There is a possibility that these batteries may lead to fire or explosion. Please be advised that Leica Camera AG is not liable for any accident or failure occurring as a result of use of a counterfeit battery.

  • Page 14: Inserting The Battery

    • Store batteries e.g. in a case so that their terminals cannot be shorted by metallic objects. ● To remove the battery, turn the camera off and wait until the LEICA indicator on the monitor goes off. (Failing to wait may cause the camera to malfunction and may damage the card or recorded data.)

  • Page 15: Charging The Battery

    Charging the battery Charging the battery We recommend charging in a location where the ambient temperature is between 10°C and 30°C (50°F to 86°F) (same for the battery temperature). Set the camera ON/OFF switch to OFF Charger Align the marks ( to ) and insert the plug.

  • Page 16: Remaining Battery Capacity

    Charging the battery ■ Charging lamp indications On: Charging in progress Off: Charging is completed (After charging stops, disconnect the camera from the mains outlet or your computer.) ■ Notes on charging time Charging time Approx. 260 min • The charging time indicated above is the time required for charging when the battery is completely depleted.

  • Page 17: Guidelines For The Number Of Recordable Pictures And Operating Time

    Charging the battery Guidelines for the number of recordable pictures and operating time The number of recordable pictures or available operating time may vary according to surrounding environment and usage conditions. Figures may be reduced if flash, zoom, or other functions are used frequently, or in colder climates. ■...

  • Page 18: Recording Motion Pictures

    Charging the battery ■ Recording motion pictures [Rec Mode] [AVCHD] [MP4] [GPH] [GFS] [Rec Quality] [FHD] [PSH] [FSH] ∗ Available recording time Approx. 55 min Approx. 65 min Approx. 70 min ∗ Approx. 30 min Approx. 35 min Approx. 40 min Actual available recording time ●...

  • Page 19: Inserting And Removing The Memory Card

    Keep the Memory Card out of reach of children to prevent swallowing. ● To remove the card, turn the camera off and wait until the LEICA indicator on the monitor goes off. (Failure to wait may cause the camera to malfunction and may damage the card or recorded data.)

  • Page 20: Picture Save Destination (Memory Card / Built-In Memory)

    Picture save destination (memory card / built-in memory) Pictures will be saved to a card if one is inserted, or to the built-in memory if not. ■ Built-in memory (approx. 12 MB) ● You can store only still pictures. ● Pictures may be copied between cards and the built-in memory.

  • Page 21: Displaying The Picture Recording Capacity

    Picture save destination (memory card / built-in memory) Displaying the picture recording capacity Estimated remaining pictures or recording time capacity (press [DISP.] button to switch display) Displayed when no card is inserted (pictures will be saved to built-in memory) While the camera is accessing the card or the built-in memory (for an operation such as picture writing, reading, deletion, or formatting), do not turn off the camera or remove the battery, the card, or disconnect the charger.

  • Page 22: Recording Capacity Guidelines (Pictures/Recording Time)

    Picture save destination (memory card / built-in memory) Recording capacity guidelines (pictures/recording time) The number of pictures you can take and the recording time vary in proportion to card capacity (and depending on recording conditions and type of card). ■ Recording picture capacity (still pictures) [Picture Size] Built-in memory...

  • Page 23: Setting The Clock

    Setting the clock The clock is not set when the camera is shipped. Set the REC/PLAY switch to before turning on the power. Turn on the power Press [MENU/SET] while the message is displayed Press to select the language, and then [MENU/SET] The [Please set the clock] message appears.

  • Page 24: Changing The Time Setting

    Setting the clock Press to select [Yes] and then [MENU/SET] if you want the time to be corrected automatically by the GPS function • To manually set date and time → select [No]. • When you select automatic time adjustment using the GPS function, [GPS Setting] is set to [ON].

  • Page 25: Sequence Of Operations

    Sequence of operations Turn on the power Set to Set to the desired recording mode Align the desired mode on the dial → exactly opposite the index mark. For taking pictures with snapshot mode [Snapshot Mode] (with extended automatic settings). (→31) For taking pictures with automatic exposure [Program AE] Mode control.
  • Page 26 Sequence of operations Aim the camera and shoot ■ To take still pictures Motion picture release button Press the shutter release button halfway to focus Press and hold the button to take the picture ■ To record motion pictures Press the motion picture release button to start recording Microphone Press the button again to finish recording...

  • Page 27: Taking Pictures With Automatic

    Taking pictures with automatic exposure control [Program AE] mode Recording mode: Use the [Rec] menu to change settings and set up your own recording environment. • Slide the REC/PLAY switch to Set to Take the picture Press halfway Press fully (press lightly to save (press the button all the focus and exposure...

  • Page 28: Storing A Focus Setting

    Storing a focus setting When [AF Mode] is set to (1-area-focusing), the camera focuses on the objects detected in the area defined by the AF marks in the center of the screen. If you wish to place a correctly focused subject off-center, follow the steps below. Focus on the desired subject Aim the AF-area at Focus display...

  • Page 29: Releasing The Shutter By Touch Operation

    Releasing the shutter by touch operation (Touch Shutter function) This function enables you to focus on the desired subject and release the shutter simply by touching the respective subject on the screen. Touch on the screen • The icon changes to , and you can now proceed with touch shutter release operation.

  • Page 30: Locking Focus And Exposure Settings With Touch Operation

    Locking focus and exposure settings with touch operation (Touch AF/AE function) This function enables you activate the focus and exposure settings by touching the desired subject on the screen. • Perform these operations with the touch shutter function (→29) deactivated. Touch the desired subject on which the focus and exposure settings should be based •...

  • Page 31: Taking Pictures With [Snapshot Mode]

    Taking pictures with [Snapshot Mode] Recording mode: Optimum settings are made automatically by the camera based on information such as “face”, “movement”, “brightness”, and “distance” just by pointing the camera at the subject. This results in sharp and well-exposed pictures without the need to make settings manually.

  • Page 32: Automatic Scene Detection

    Taking pictures with [Snapshot Mode] Automatic Scene Detection The camera recognizes many scene types based on the captured subjects, and makes optimum settings automatically. A person was recognized ∗ A baby was recognized A landscape was recognized A night scene with persons was recognized ∗...

  • Page 33: [Motion Deblur]

    Taking pictures with [Snapshot Mode] [Motion Deblur] The camera automatically sets the optimum shutter speed in accordance with the movements of the subject to minimize the blur of the subject. ■ Settings Press [MENU/SET] Use the respective cursor buttons to select [Rec] menu and press [MENU/SET] Use the respective cursor buttons to select [Motion Deblur] and press [MENU/SET] Use the respective cursor buttons to select [ON] and press [MENU/SET] ●...

  • Page 34: [Ihdr] (Intelligent High Dynamic Range)

    Taking pictures with [Snapshot Mode] [iHDR] (intelligent High Dynamic Range) When [iHDR] is set to [ON], the camera creates a single properly exposed picture with rich gradation by combining the image data of several differently exposed shots. ■ Settings Press [MENU/SET] Use the respective cursor buttons to select [Rec] menu and press [MENU/SET] Use the respective cursor buttons to select [iHDR] and press [MENU/SET] Use the respective cursor buttons to select [ON] and press [MENU/SET]...

  • Page 35: Af Tracking

    Taking pictures with [Snapshot Mode] AF Tracking This function enables the camera to adjust both the focus and exposure settings continuously for a predetermined moving subject. ■ With touch screen operations Perform these operations with the touch shutter function (→29) deactivated. Touch the subject •...

  • Page 36: [Snapshot Mode] Restrictions

    Taking pictures with [Snapshot Mode] [Snapshot Mode] restrictions Only the menu items which are displayed in the [Snapshot Mode] can be set. The settings selected in the [Program AE] or other modes will reflect on the menu items in the [Setup] menu that are not displayed. ●...

  • Page 37: Taking Motion Pictures

    Taking motion pictures Recording modes: You can record motion pictures with audio (stereo). • Slide the REC/PLAY switch to • Motion pictures cannot be recorded in the built-in memory. Do not cover the microphone when recording motion pictures. Press the motion picture release button to start recording [Rec Mode] (→106)/[Rec Quality] (→107) Elapsed recording time...
  • Page 38 Taking motion pictures ■ About the recording format for recording motion pictures This camera can record motion pictures in either AVCHD or MP4 formats. AVCHD: This format allows recording high definition quality images. It is suitable for viewing on a large format TV or for saving to disc. AVCHD Progressive: With camera models 18 176 / 18 177 [GPH] or [PSH] in [AVCHD] is a mode that allows motion pictures to be recorded at...
  • Page 39 Taking motion pictures ■ Recording motion pictures in Records a motion picture at your preferred settings. • Aperture and shutter speed are automatically set. ■ Recording motion pictures in The camera automatically determines the scene mode to record motion pictures with optimal settings.
  • Page 40 Taking motion pictures ● If the surrounding temperature is high, or a motion picture is recorded continuously, is displayed and recording may be stopped halfway through to protect the camera. (Only when [Rec Quality] is set to [GPH], [PSH], [GFS] or [FSH]) ●...

  • Page 41: Recording Still Pictures While A Motion Picture Is Being Recorded

    Taking motion pictures Recording still pictures while a motion picture is being recorded Still pictures can be recorded even while a motion picture is being recorded. Press the shutter release button fully during the motion picture recording Still pictures are recorded with an [Aspect Ratio] setting of 16:9 and a [Picture Size] setting of 3.5 M.

  • Page 42: Viewing Your Pictures

    Viewing your pictures [Normal Play] When a card is in the camera, pictures are played back from the card, without a card, they are played back from the built-in memory. • Slide the REC/PLAY switch to Drag your finger across the screen, and select the picture to be played back Scrolling to the next picture: Drag your finger across the screen from right to left.

  • Page 43: Viewing An Enlarged Section

    Viewing your pictures Viewing an enlarged section (Playback Zoom) Touch the area that you want to magnify Each time you touch, the magnification increases through four levels after 1x: 2x, 4x, 8x, and 16x. (The picture quality displayed becomes successively lower.) •...

  • Page 44: Viewing Pictures By Their Recording Date

    Viewing your pictures Viewing pictures by their recording date (Calendar Playback) Move the zoom lever towards the W side several times Touch the recording date to be displayed, and [Set] to enter the date Select the month The pictures recorded on the selected date appear on the 12-picture screen. •...

  • Page 45: Viewing Motion Pictures

    Viewing motion pictures This camera was designed to play motion pictures using the AVCHD, MP4 and QuickTime Motion JPEG formats. • Slide the REC/PLAY switch to Select a picture with the motion picture icon, and touch Playback now starts. • You can also press to play back motion pictures.
  • Page 46 Viewing motion pictures ● You can also use the respective cursor buttons to perform playback operations. : Pause/play : Stop : Fast rewind (2 steps)/Single-frame rewind (while paused) : Fast forward (2 steps)/Single-frame forward (while paused) [MENU/SET]: Capturing still pictures from motion pictures (→47) •...

  • Page 47: Capturing Still Pictures From Motion Pictures

    Viewing motion pictures Capturing still pictures from motion pictures Save a scene from a motion picture as a still picture. Display the picture that you want to capture as a still picture by pausing a motion picture during playback Touch •...

  • Page 48: [Video Divide]

    Viewing motion pictures [Video Divide] A single motion picture take can be split into 2 parts. This is convenient, e.g. when you want to keep just the necessary scenes, or if you wish to delete unnecessary scenes to increase free space on your card, such as when travelling. Select a motion picture to be split and then touch •...

  • Page 49: Deleting Pictures

    Deleting pictures Pictures will be deleted from the card if one is inserted, or from the built-in memory if no card is inserted. (Deleted pictures cannot be recovered.) Press to delete the displayed picture • A confirmation screen is displayed. Select [Yes] with the respective cursor buttons and then press [MENU/SET].

  • Page 50: Deleting Multiple (Up To 100)/Deleting All Pictures

    Deleting pictures Deleting multiple (up to 100)/Deleting all pictures A serial exposure group is handled as one picture. (All the pictures in the selected serial exposure group are deleted.) Press to delete the displayed picture to select [Delete Multi]/ [Delete All] and press [MENU/SET] ●...

  • Page 51: Setting The Menu

    Setting the menu Refer to the procedure below for an example on how to operate the menus. Press [MENU/SET] The menu selection screen is displayed. Use the respective cursor buttons to select a menu, and then press [MENU/SET] • The menu type can also be selected by touch operations.

  • Page 52: Menu Types

    Setting the menu Menu types [Rec] menu (→95) (Recording mode only) • You can perform settings such as tones, Sensitivity, Aspect Ratio, and resolution. [Motion Picture] menu (→106) (Recording mode only) • You can select the recording mode and picture quality and other settings. [GPS] menu (→127) •...

  • Page 53: Using The Quick Menu

    Setting the menu Using the Quick menu During recording, you can easily call some of the menu items and set them. Press the [Q.MENU] button Press to select a menu item • The menu items and setting items that are displayed differ depending on the recording mode.

  • Page 54: Using The [Setup] Menu

    Using the [Setup] menu [Clock Set], [Economy] and [Auto Review] are important for clock setting and battery life. Please check these before use. • For details about the setting procedure in the [Setup] menu (→51) Item Settings, notes For setting time, date, and display format. [Clock Set] (→23) [ON] / [OFF]...

  • Page 55: [Volume]

    Using the [Setup] menu • For details about the setting procedure in the [Setup] menu (→51) Item Settings, notes [0] / [1] / [2] / [3] / [4] / [5] / [6] [Volume] • Cannot be used to adjust TV speaker volume when For adjusting the speaker connected to a TV.

  • Page 56: [Guide Line]

    Using the [Setup] menu • For details about the setting procedure in the [Setup] menu (→51) Item Settings, notes [Rec. Info.] [Guide Line] [ON] (Displays recording information with guidelines.) For selecting recording [OFF] information display and the types of guidelines. [Pattern] : Changes the patterns of guidelines.

  • Page 57: [Economy]

    Using the [Setup] menu • For details about the setting procedure in the [Setup] menu (→51) Item Settings, notes [Sleep Mode] [Economy] For turning off the power [2MIN.] / [5MIN.] / [10MIN.] / [OFF]: or the monitor while Automatically switches the camera off when it is not being not using the camera used.

  • Page 58: [No.reset]

    Using the [Setup] menu • For details about the setting procedure in the [Setup] menu (→51) Item Settings, notes • The folder number is updated and the file number starts [No.Reset] from 0001. For resetting picture file • A folder number between 100 and 999 can be assigned. numbers.

  • Page 59: [Output]

    Using the [Setup] menu • For details about the setting procedure in the [Setup] menu (→51) Item Settings, notes [Output] [Video Out] (With camera model 18 175) Changes the settings [NTSC] / [PAL] to be used when the If the default setting is changed, AVCHD motion pictures camera is connected to a may not be played correctly.

  • Page 60: [Rotate Disp.]

    • Formatting the built-in memory may take several the data cannot be minutes. restored. Check the • Consult your Leica dealer or the nearest Leica Customer content of the card/ Care center if formatting cannot be successfully the built-in memory completed.

  • Page 61: Language

    Using the [Setup] menu • For details about the setting procedure in the [Setup] menu (→51) Item Settings, notes Sets the language displayed on the screen. [Language] For changing the display language. Extent of camera shake is shown on graph (estimate) [O.I.S.

  • Page 62: Recording

    Changing recording information display For switching between different monitor displays, such as Histograms. Press the [DISP.] button to change the display ● In Recording Mode Recording Motion picture recording ∗ ∗ ∗ ∗ ∗ information information No display Guide lines ●...

  • Page 63: Using The Zoom

    Using the zoom Recording modes: You can determine how much of a subject you wish to capture by using the lens’s zoom function. Zooming in/out For capturing For capturing a smaller, a larger area but also enlarged area (wide-angle) (telephoto) •...

  • Page 64: Zooming With Touch Operation

    Using the zoom Zooming with touch operation Touch The zoom bar appears on the screen. Touch the T or W edge of the zoom bar on the screen Fast zooming all the way to the T end ∗ Fast zooming Fast zooming all the way to the W end ∗...

  • Page 65: Zoom Modes And Their Application

    Using the zoom Zoom modes and their application The zoom ratio changes when the resolution is changed. ■ Optical zooming Zooming up to a ratio of 20x is possible if recording without is selected with [Picture Size] in the [Rec] menu. (→95) ●...

  • Page 66: Taking Pictures With Flash

    Taking pictures with flash Recording modes: Press to display [Flash] Use the respective cursor buttons to select the desired mode and press [MENU/SET] Type, operations Uses [Auto] For normal use ∗ • Flash is activated automatically when necessary ∗ [Auto/Red-Eye] For taking pictures of subjects in dark •...

  • Page 67: Available Flash Modes

    Taking pictures with flash ■ Available flash modes (○: Available, –: Not available, : Default setting) [Scene Mode] ∗ – ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ – – – – – – ○ ○ ○ ○ ○...

  • Page 68: Taking Close-Up Pictures

    Taking close-up pictures Recording modes: When you want to enlarge the subject, setting to [AF Macro] ( ) enables you to take pictures at an even closer distance than the normal focus range (up to 3 cm (1 inch) for max. W). Press to display [Macro Mode] Use the respective cursor buttons to select [AF Macro] and...

  • Page 69: [Macro Zoom]

    Taking close-up pictures [Macro Zoom] To take even larger images of the subject than when using [AF Macro], select [Macro Zoom]. Press to display [Macro Mode] Use the respective cursor buttons to select [Macro Zoom] and press [MENU/SET] Adjust the Digital Zoom magnification with the zoom lever The zoom position is fixed at the Wide end.

  • Page 70: Taking Pictures With The Self-Timer

    Taking pictures with the self-timer Recording mode: We recommend using a tripod. This mode can also be used to prevent the camera shake effect caused by pressing the shutter release button. To do so, set the self-timer to 2 seconds. Press to display [Selftimer] Use the respective cursor buttons to select time duration and...

  • Page 71: Taking Pictures With Exposure Compensation

    Taking pictures with Exposure Compensation An exposure compensation allows adjusting the exposure when the desired brightness level is not attained automatically (e.g. when there are different brightness levels within the picture). ■ Recording modes: Press to display [Exposure] Use the respective cursor buttons to select a value and press [MENU/SET] •...

  • Page 72: Taking Picture Series With Automatically Changed Exposure

    Taking pictures with Exposure Compensation Taking picture series with automatically changed exposure 3 pictures in continuous succession are recorded while the exposure is changed automatically. If an exposure compensation value is set, the adjusted exposure is set as the standard. ■...

  • Page 73: Using A Pre-Set Aperture To Determine The Depth Of Field - [Aperture-Priority] Mode

    Using a pre-set aperture to determine the depth of field - [Aperture-Priority] Mode Recording mode: By setting the aperture value manually, you can determine the depth of field (i.e. how much of the subject is rendered sharply) to suit your compositional intentions. The shutter speed is automatically adjusted accordingly.

  • Page 74: Using A Pre-Set Shutter Speed To Determine The Rendition Of Moving Subjects - [Shutter-Priority] Mode

    Using a pre-set shutter speed to determine the rendition of moving subjects - [Shutter-Priority] Mode Recording mode: By setting the shutter speed manually, you can determine how sharp moving subjects are rendered. The aperture value is automatically adjusted accordingly. Set the mode dial to ([Shutter-Priority] Mode) Press the [EXPOSURE] button and use the respective cursor buttons to determine shutter speed...

  • Page 75: Using A Pre-Set Aperture/Shutter Speed Combination To Achieve Full Control Of The Exposure - [Manual Exposure] Mode

    Using a pre-set aperture/shutter speed combination to achieve full control of the exposure - [Manual Exposure] Mode Recording mode: This mode, in which you set both aperture and shutter speed manually gives you full control of the exposure, i.e. of how bright a subject is rendered. Also, long-exposure recording of up to 15 seconds is possible.

  • Page 76: Taking Pictures With Different Picture Effects [Creative Control] Mode

    Taking Pictures with different picture effects [Creative Control] mode Recording mode: You can select various effects for taking pictures and get the results displayed on the monitor. Set the mode dial to Press to select a setting, and then [MENU/SET] Setting Effect [EXPS]...
  • Page 77 Taking Pictures with different picture effects [Creative Control] mode ■ Changing the selected picture effects ([Creative Control] menu) Press [MENU/SET] Use the respective cursor buttons to select [Creative Control] menu and press [MENU/SET] Press to select a setting, and then [MENU/SET] ■...

  • Page 78: Taking Pictures With Settings Matched To The Encountered Scene [Scene Mode]

    Taking pictures with settings matched to the encountered scene [Scene Mode] Recording mode: Using [Scene Mode] enables you to take pictures with optimum settings (exposure, coloring, etc.) for given scenes. Set the mode dial to Use the respective cursor buttons to select the scene and press [MENU/SET] ■...

  • Page 79: [Portrait]

    Taking pictures with settings matched to the encountered scene [Scene Mode] • How to select a scene (→78) • About using flash in Scene Modes (→66) This mode improves the skin tone of subjects for a healthier appearance in bright daylight conditions. [Portrait] •...
  • Page 80 Taking pictures with settings matched to the encountered scene [Scene Mode] • How to select a scene (→78) • About using flash in Scene Modes (→66) • Pan the camera in the recording direction as steadily as possible. If the camera shakes too much, it may not be able to take pictures or may end up creating a narrow (small)

  • Page 81: [Sports]

    Taking pictures with settings matched to the encountered scene [Scene Mode] • How to select a scene (→78) • About using flash in Scene Modes (→66) This mode is for pictures of scenes with fast movement, e.g. sports. • Stand at least 5 m (16 feet) away. [Sports] Note •...

  • Page 82: [Hdr]

    Taking pictures with settings matched to the encountered scene [Scene Mode] • How to select a scene (→78) • About using flash in Scene Modes (→66) In this mode, the camera can combine several still pictures taken with different exposures into a single picture with rich gradation. •...

  • Page 83: [Sunset]

    Taking pictures with settings matched to the encountered scene [Scene Mode] • How to select a scene (→78) • About using flash in Scene Modes (→66) For taking sharp pictures of scenes such as sunsets. [Sunset] This mode prevents blurring of subjects in dark, indoor conditions. Select the aspect ratio and the picture size with cursor button and press [MENU/ [High Sens.] SET].

  • Page 84: Taking 3D Pictures

    Taking 3D pictures [3D Photo Mode] Recording mode: The camera continuously records multiple still pictures while being moved horizontally, and combines two of them into a 3D still picture. To view 3D pictures, a television that supports 3D is required (This camera will play back in 2D).

  • Page 85: Registering Your Own Setting Combinations [Custom] Mode

    Registering your own setting combinations [Custom] Mode Registering your preferred recording mode, [Rec] menu settings, etc. to [Cust.Set Mem.] and setting the mode dial to allows you to switch quickly to those settings. [Cust.Set Mem.] Up to 4 current camera settings can be registered. ■...

  • Page 86: [Custom]

    Registering your own setting combinations [Custom] Mode [Custom] Settings registered in [Cust.Set Mem.] can be quickly called up by setting the mode dial ■ Recording modes: Set the mode dial to ([Custom] mode) • When set to → The camera switches to the recording mode and settings registered in •...

  • Page 87: Taking Picture Series

    Taking picture series Recording modes: Series of consecutive pictures can be taken by keeping the shutter button fully pressed. Select [Burst] from the [Rec] menu (→51) Use the respective cursor buttons to select the exposure series setting, and press [MENU/SET] No.
  • Page 88 Taking picture series ■ Possible resolution settings [Aspect Ratio] 5 M, 3 M, 0.3 M 2.5 M, 0.3 M 4.5 M, 2.5 M, 0.3 M 3 M, 0.3 M 2.5 M 16:9 3.5 M, 2 M, 0.2 M 3.5 M, 0.2 M 3.5 M, 2.5 M, 0.2 M 2 M, 0.2 M 2.5 M...

  • Page 89: Taking Pictures With The Face Recognition Function

    Taking pictures with the Face Recognition function [Face Recog.] Recording modes: • The default [Face Recog.] setting is [OFF]. • When faces are registered, the setting will be [ON] automatically. ■ How the Face Recognition function works During recording (When [AF Mode] is (Face Detection)) •...

  • Page 90: Registering Faces

    Taking pictures with the Face Recognition function Registering faces Up to 6 person’s faces can be registered along with such information as name and birthdate. You can improve the Face Recognition by registering a face more than once. Up to 3 pictures can be utilized to register a face.

  • Page 91: Editing Or Deleting Information About Registered Persons

    Taking pictures with the Face Recognition function Editing or deleting information about registered persons Information about registered people can be edited or deleted. Select [Face Recog.] in the [Rec] menu (→51) Select [MEMORY] with the respective cursor buttons and then press [MENU/SET] Use the respective cursor buttons to select the face to be edited or deleted...

  • Page 92: Useful Features For Travel

    Useful features for travel [Travel Date] • For [Setup] menu setting procedures (→51) If you set your travel schedule and take pictures, the day of your trip on which they were taken will be registered. ■ ∗ Recording modes: ∗ Recording only.

  • Page 93: [World Time]

    Useful features for travel [World Time] • For [Setup] menu setting procedures (→51) Set the recording date and time with the local time at your destination. ■ Recording modes: ■ Preparation: Set [Auto Clock Set] to [OFF]. (→139) Select [World Time] from the [Setup] menu (→51) •...

  • Page 94: Entering Text

    Entering Text Use the respective cursor buttons to enter names with the Face Recognition function and in Scene Modes [Baby] and [Pet], or to register locations in [Travel Date] etc. Use the respective cursor buttons to select characters Press [MENU/SET] several times until the desired character is displayed The text is inserted at the cursor position.

  • Page 95: Using The [Rec] Menu

    Using the [Rec] menu [Aspect Ratio] • For [Rec] menu setting procedures (→51) The aspect ratio of still picture can be changed according to printing or playback format. ■ Recording modes: ■ Settings: ● The edges may be cut off when printing – be sure to check in advance. [Picture Size] •...

  • Page 96: [Quality]

    Using the [Rec] menu [Quality] • For [Rec] menu setting procedures (→51) For setting the quality of picture. ■ Recording modes: ■ Settings: ([Fine]) High quality, priority to picture quality ([Standard]) Standard quality, priority to the number of pictures ● The setting is fixed to , in [High Sens.] Scene Mode.

  • Page 97: [White Balance]

    Using the [Rec] menu [White Balance] • For [Rec] menu setting procedures (→51) Adjust the coloring to suit the light source if colors otherwise appear unnatural. ■ Recording modes: ■ Settings: [AWB] (automatic) / (outdoor, clear sky) / (outdoor, cloudy sky) / (outdoor, shade) / (Incandescent lighting) / (uses value set in...
  • Page 98 Using the [Rec] menu ■ Setting White Balance manually ( Select and press [MENU/SET] Point the camera at a white object (e.g. paper) and press [MENU/SET] White Balance is set to • Even if the camera’s power is OFF, the White Balance setting is remembered. •...

  • Page 99: [Af Mode]

    Using the [Rec] menu [AF Mode] • For [Rec] menu setting procedures (→51) The focus setting mode can be changed according to position and number of subjects. ■ Recording modes: ■ Settings: Taking front-on Recognizes faces (up to 15 persons) and adjusts exposure and pictures of persons focus accordingly.

  • Page 100: [Quick Af]

    Using the [Rec] menu ● Focus is fixed to (1-area-focusing) in the following cases: • [High Speed Video] scene mode • [Miniature Effect] in [Creative Control] mode ● (1-area-focusing) if focusing is difficult with (Spot-focusing). ● (Face Detection) cannot be set the following cases: •...

  • Page 101: [Face Recog.]

    Using the [Rec] menu [Face Recog.] • For [Rec] menu setting procedures (→51) For details (→89). [Metering Mode] • For [Rec] menu setting procedures (→51) This function allows adapting the metering mode to different subjects and situations. ■ Recording modes: ■...

  • Page 102: [Min. Shtr Speed]

    Using the [Rec] menu [Min. Shtr Speed] • For [Rec] menu setting procedures (→51) Allows extending the shutter speed range for automatic exposure control modes. We recommend using slower shutter speeds to take brighter pictures in dark locations. ■ Recording modes: ■...

  • Page 103: [Burst]

    Using the [Rec] menu [Burst] • For [Rec] menu setting procedures (→51) For details (→87). [Color Mode] • For [Rec] menu setting procedures (→51) For setting color effects. ■ Recording modes: ■ Settings: [STANDARD] / [VIVID] ∗ (sharper) / [B&W] / [SEPIA] / [Happy] ∗ ∗...

  • Page 104: [Red-Eye Removal]

    Using the [Rec] menu [Red-Eye Removal] • For [Rec] menu setting procedures (→51) This mode automatically detects the red-eye effect and corrects still picture data when recording with flash red-eye reduction ( ■ Recording modes: ■ Settings: [ON] / [OFF] ●...

  • Page 105: [Date Stamp]

    Using the [Rec] menu [Date Stamp] • For [Rec] menu setting procedures (→51) Still pictures can be taken with the recording date and time stamped on the still picture. ■ Recording modes: ■ Settings: [W/O TIME] / [WITH TIME] / [OFF] ●...

  • Page 106: Using The [Motion Picture] Menu

    Using the [Motion Picture] menu [Rec Mode] • For [Motion Picture] menu setting procedures (→51) For setting the data format of the motion picture that is recorded. ■ Recording modes: ■ Settings: [AVCHD] • This is a data format suitable for playback on high-definition TVs. •...

  • Page 107: [Rec Quality]

    Using the [Motion Picture] menu [Rec Quality] • For [Motion Picture] menu setting procedures (→51) For setting the resolution of the motion picture that is recorded. ■ Recording modes: ■ Settings: [AVCHD] in [Rec Mode] Item Resolution/Bit rate [Aspect Ratio] [GPH] ∗...

  • Page 108: [Continuous Af]

    Using the [Motion Picture] menu [Continuous AF] • For [Motion Picture] menu setting procedures (→51) This mode allows either constant focusing during motion picture recording, or determining the focus setting at the start of recording. ■ Recording modes: ■ Settings: [ON] [OFF]: Determines the focusing setting at the start of motion picture recording.

  • Page 109: Playing Back Still Pictures Recorded Using The Serial Exposure Function

    Playing back still pictures recorded using the serial exposure function Pictures taken with the setting are recorded together as a group (serial exposure group). ■ Representative picture display A representative picture (first picture of the series) is displayed when it is displayed together with other still pictures or with motion pictures.
  • Page 110 Playing back still pictures recorded using the serial exposure function ● [Playback] menu items cannot be used while the display appears within each serial exposure group. ● Serial exposure picture cannot be displayed as a group during [GPS Area Play] or [Favorite] playback with [Slide Show] or [Filtering Play].

  • Page 111: Different Playback Methods

    Different playback methods [Playback Mode] Recorded pictures can be played back in a variety of ways. Press [MENU/SET] in playback mode The menu selection screen is displayed. Use the respective cursor buttons to select [Playback Mode] menu and press [MENU/SET] •...

  • Page 112: [Slide Show]

    Different playback methods [Slide Show] • For switching [Playback Mode] (→111) For automatically playing back pictures in a certain order and to music. Recommended when viewing on TV screen. Use the respective cursor buttons to select the playback method and press [MENU/SET] [All] Plays back all pictures.
  • Page 113 Different playback methods ■ Operations during Slide Show The operation guide appears on the bottom right of the monitor. • If you do not perform any operation for approx. 2 seconds, the operation guide is turned off. To display the guide again, press the [DISP.] button. During motion picture/ During still picture playback serial exposure group/...

  • Page 114: [Filtering Play]

    Different playback methods [Filtering Play] • For switching [Playback Mode] (→111) You can refine the selection of pictures to be viewed by narrowing them down to pictures in selected categories or to favorite pictures, and then view those pictures. Select the filtering method using the respective cursor buttons, and press [MENU/SET] [Picture Only] Plays back still pictures...

  • Page 115: Retouching Pictures

    Retouching pictures [Auto Retouch] With this mode, you can adjust the color and brightness of a still picture to bring them into balance. • New pictures are created after editing pictures with [Auto Retouch]. Before starting to edit, make sure that there is enough free space in the built-in memory or the memory card.

  • Page 116: [Creative Retouch]

    Retouching pictures [Creative Retouch] With this mode, you can retouch recorded still pictures by selecting the effect that you want to apply. • New pictures are created after editing pictures with [Creative Retouch]. Before starting to edit, make sure that there is enough free space in the built-in memory or the memory card.

  • Page 117: Using The [Playback] Menu

    Using the [Playback] menu With this mode, you can edit a selected picture (e.g. trim it), mark it as protected, a.s.o.. • For [Playback] menu display and operation methods (→51) • Depending on the [Playback Mode], some [Playback] menu items are not displayed. •...

  • Page 118: [Text Stamp]

    Using the [Playback] menu [Text Stamp] • For [Playback] menu display and operation methods (→51). With this mode, the recording date and time, location name information and the text registered in the [Baby], [Pet] Scene Modes, [Travel Date] and [Title Edit] can be stamped on the still picture.
  • Page 119 Using the [Playback] menu ■ Items that can be stamped [Shooting Date] [W/O TIME]: Stamps the recording date [WITH TIME]: Stamps recording date and time [Name] : Stamps the name registered in Face Recognition : Stamps the name registered in [Baby] or [Pet] [Location] Stamps the location registered in [Setup] menu’s [Travel Date] [Travel Date]...

  • Page 120: [Resize]

    Using the [Playback] menu [Resize] • For [Playback] menu display and operation methods (→51). With this mode, the resolution can be reduced to facilitate e-mail attachment and use in web pages, etc. (Still pictures recorded at the smallest recording pixel level cannot be further reduced.) ■...

  • Page 121: [Cropping]

    Using the [Playback] menu [Cropping] • For [Playback] menu display and operation methods (→51). For enlarging your still pictures and cropping unwanted areas. Use the respective cursor buttons to select a still picture, and then press [MENU/SET] Select the area to crop and press [MENU/SET] Expand Change position •...

  • Page 122: [Favorite]

    Using the [Playback] menu [Favorite] • For [Playback] menu display and operation methods (→51). By labelling your favorite pictures with a star ( ), you can play back your favorite pictures only, or you can delete all pictures except your favorites. Use the respective cursor buttons to select [SINGLE] or [MULTI] and press [MENU/SET] Use the respective cursor buttons to select picture and press...

  • Page 123: [Print Set]

    Using the [Playback] menu [Print Set] • For [Playback] menu display and operation methods (→51). With this mode, picture/picture no./date printing settings can be made for when printing with DPOF print-compatible shops or printers. (Ask at the shop to check for compatibility.) Use the respective cursor buttons to select [SINGLE] or [MULTI] and press [MENU/SET] Use the respective cursor buttons to select picture and press...

  • Page 124: [Protect]

    Using the [Playback] menu [Protect] • For [Playback] menu display and operation methods (→51). For setting protection to disable picture deletion. Prevents deletion of important pictures. Use the respective cursor buttons to select [SINGLE] or [MULTI] and press [MENU/SET] Use the respective cursor buttons to select picture and press [MENU/SET] ●...

  • Page 125: [Face Rec Edit]

    Using the [Playback] menu [Face Rec Edit] • For [Playback] menu display and operation methods (→51). For editing or deleting the recognition information for pictures with mistaken Face Recognition. Use the respective cursor buttons to select [REPLACE] or [DELETE] and press [MENU/SET] Use the respective cursor buttons to select the picture and press [MENU/SET] Use the respective cursor buttons to select a person and...

  • Page 126: [Copy]

    The following settings are not copied. Set them again after copying. - [Print Set] - [Protect] - [Favorite] ● Only pictures from Leica digital cameras (exceptions: Digilux, Digilux4.3, Digilux Zoom) may be copied. ● Motion pictures recorded in [AVCHD] format cannot be set. - 126 -...

  • Page 127: Using The Gps Function To Record The Picture Taking Location

    Using the GPS function to record the picture taking location Before using the GPS function, read “About GPS” (→8) and “Licence Agreement for Place Name and Map Data” (→188). GPS stands for Global Positioning System. You can check your current location using GPS satellites.

  • Page 128: Using The Gps Function To Execute Positioning

    Using the GPS function to record the picture taking location Using the GPS function to execute positioning When [GPS Setting] is [ON], the camera periodically receives radio signals from the GPS satellites and executes positioning. When positioning is executed successfully, the place name and position (latitude and longitude) information are recorded in still pictures and motion pictures (except for the picture quality settings of [PSH], [FSH], and [SH]).

  • Page 129: Displaying The Status And Result Of Positioning

    Using the GPS function to record the picture taking location ■ Displaying the status and result of positioning The icons that indicate the status and result of positioning will appear on the monitor. When the camera successfully executes positioning, it records the current location and displays the place name information on the screen.
  • Page 130 Using the GPS function to record the picture taking location ■ Information to be recorded on the pictures When the camera successfully executes positioning, it records the following information in still pictures and motion pictures ∗ (except for the picture quality settings of [PSH], [FSH], and [SH]).

  • Page 131: Executing The Positioning Function Immediately To Update The Current Location

    Using the GPS function to record the picture taking location Executing the positioning function immediately to update the current location If the displayed place name is different from the current location or a previous location is displayed, update the positioning information. If some time has elapsed since the last time positioning was executed successfully ( , or...
  • Page 132 Using the GPS function to record the picture taking location ■ Interval between positioning operations Even if the positioning information is not updated, the camera automatically tries to execute positioning immediately after it is turned on and subsequently at regular intervals when [GPS Setting] is [ON].

  • Page 133: Changing Place Name Information To Be Displayed

    Using the GPS function to record the picture taking location Changing place name information to be displayed You can change the recorded place name information items to be displayed on the screen. Press [MENU/SET] Use the respective cursor buttons to select [GPS] menu and press [MENU/SET] Use the respective cursor buttons to select [Area Info.

  • Page 134: Disabling The Positioning Function When The Camera Is Turned Off

    Using the GPS function to record the picture taking location Disabling the positioning function when the camera is turned off When [GPS Setting] is [ON], the GPS function remains activated even if the camera is turned off. To disable the positioning function when the camera is turned off, set [Airplane Mode] to [ON].

  • Page 135: Changing The Place Name Information To Be Recorded

    Changing the place name information to be recorded When there are other candidate locations as a result of positioning, you can change the location information to another place name or landmark in the neighborhood. • When there is a choice for differing place name information, appears in front of the place name information.

  • Page 136: Changing The Recorded Gps Information

    Changing the recorded GPS information [Edit Location] You can edit the location information (latitude and longitude) recorded on still pictures and motion pictures. • You can edit the location information only on a picture ( appears on the screen when this picture is played back) recorded with GPS information (location and place name information) when it was taken.
  • Page 137 Changing the recorded GPS information ■ Specifying the location from the map Use the respective cursor buttons to select [Point on map] and press [MENU/SET] Move the map to a new location that you want to record on the picture and press [MENU/SET] •...

  • Page 138: [Edit Place Name]

    Changing the recorded GPS information [Edit Place Name] You can edit a place name or landmark name recorded in a picture. Press [MENU/SET] Use the respective cursor buttons to select [Playback] menu or [Map] menu and press [MENU/SET] Use the respective cursor buttons to select [Edit GPS Data] and press [MENU/SET] Use the respective cursor buttons to select a picture and press [MENU/SET]...

  • Page 139: Adjusting The Time Using Gps

    Adjusting the time using GPS You can automatically update the [Clock Set] of the camera using the date and time information contained in GPS radio signals. When you move to a different time zone from your home area and positioning is executed successfully, the camera automatically adjusts the time to the local time.

  • Page 140: Reducing The Time Required For Positioning

    Reducing the time required for positioning You can reduce the time required for positioning by copying the predicted satellite information (GPS assist data) of GPS satellites required for positioning to the camera in advance. • A computer that can be connected to the Internet is required to download the GPS assist data.

  • Page 141: Using The "Gps Assist Tool

    Reducing the time required for positioning Using the “GPS Assist Tool” ■ Using “GPS Assist Tool” by connecting the camera and computer Preparation: Turn on the computer and close all other open application programs. Press [MENU/SET] Use the respective cursor buttons to select [GPS] menu and press [MENU/SET] Use the respective cursor buttons to select [Assist Data] and press [MENU/SET]...
  • Page 142 Reducing the time required for positioning ■ Using a card reader/writer (commercially available) Preparation: • Turn on the computer that is connected to a card reader/writer (commercially available) and close all other open application programs. • Insert a memory card in the camera before starting the updating procedure.

  • Page 143: Updating The Gps Assist Data

    Reducing the time required for positioning Updating the GPS assist data Start up the “GPS Assist Tool” on the computer ■ Windows Double-click [GPSASIST.EXE] stored in the connected camera or memory card The “GPS Assist Tool” will start up. • When the “GPS Assist Tool” is copied to the memory card, [GPSASIST.EXE] is stored in the [AD_LEICA] folder.

  • Page 144: Checking The Expiration Date Of The Gps Assist Data

    Reducing the time required for positioning Checking the expiration date of the GPS assist data The GPS assist data expires in 30 days. We recommend using new GPS assist data. Press [MENU/SET] Use the respective cursor buttons to select [GPS] menu and press [MENU/SET] Use the respective cursor buttons to select [Assist Data] and press [MENU/SET]...

  • Page 145: Using The Map Function

    When you enlarge or reduce the map size, it may take some time before it is displayed. ● You can display the place where you took the pictures on a map only for pictures with location information or place name information recorded using Leica digital cameras equipped with a GPS function. - 145 -...

  • Page 146: Displaying Your Current Location On A Map

    Using the map function Displaying your current location on a map When positioning is executed successfully using GPS, you can display your current location on a map. • Make sure to set [GPS Setting] to [ON]. (→128) Press the [MAP] button in playback mode Touch [My Location] Time elapsed after positioning was executed successfully Touch the +/- button to enlarge or reduce the map size.

  • Page 147: Displaying Only Pictures Taken In The Same Area

    Using the map function Displaying only pictures taken in the same area You can select the area of a picture on a map to narrow down the pictures to be displayed. Press the [MAP] button in playback mode Display the map so that the place where you took the pictures is moved within the display range of the frame Display range Touch the +/- button to enlarge or reduce the map size.

  • Page 148: Displaying A Map By Selecting A Country Or Region

    Using the map function Displaying a map by selecting a country or region You can select a place name that you want to display and show it on a map. Press [MENU/SET] in playback mode Use the respective cursor buttons to select [Map] menu and press [MENU/SET] Use the respective cursor buttons to select [Select Area] and press [MENU/SET]...

  • Page 149: Using The Map Data On The Dvd

    Using the map data on the DVD You can use “LEICA Map Tool” to copy the map data on the DVD (supplied) to a memory card. When the map data is copied to the memory card, detailed maps can be displayed on the camera.

  • Page 150: Copying The Map Data To A Memory Card

    Using the map data on the DVD Copying the map data to a memory card Preparation: • Install “LEICA Map Tool” on your computer before starting the copying procedure. (→149) • Turn on the computer and close all other open application programs.
  • Page 151 When a memory card is formatted (initialized), all data, including the map data, is deleted. ● Use “LEICA Map Tool” for copying and deleting the map data. When the map data is deleted or moved to another location using the file operation of your computer, the maps may not be displayed correctly.

  • Page 152: Registering My Landmark

    Registering my landmark You can register a user-defined location that is not registered in this camera as my landmark in order to display it when positioning is executed or to record it on a picture. (Up to 50 landmarks) ● Unless the map data is copied to a memory card, My landmark cannot be registered.

  • Page 153: Registering The Recording Location As My Landmark

    Registering my landmark Registering the recording location as my landmark You can use the location information of a picture to register it as My landmark. Press [MENU/SET] in playback mode Use the respective cursor buttons to select [Map] menu or [GPS] menu and press [MENU/SET] Use the respective cursor buttons to select [My Landmark] and press [MENU/SET]...

  • Page 154: Selecting My Landmark And Displaying It On A Map

    Registering my landmark Selecting My landmark and displaying it on a map You can display a map by moving the registered My landmark to the center. Press [MENU/SET] in playback mode Use the respective cursor buttons to select [Map] menu and press [MENU/SET] Use the respective cursor buttons to select [Select Area] and press [MENU/SET]...

  • Page 155: Playing Back On A Tv

    Playing back on a TV You can view pictures on a TV by connecting your camera to it with the HDMI mini cable (available as accessory →9) or the AV cable (included in scope of delivery →9). ● Also consult the TV’s instructions. Preparation: •...
  • Page 156 Playing back on a TV ■ To connect with the HDMI mini cable ● Always use the genuine Leica HDMI mini cable (available as accessory →9). ● Some of the playback functions cannot be performed. ● [Playback], [GPS], [Map], and [Setup] menus cannot be used.

  • Page 157: Hdtv Link (Hdmi)

    The camera is compatible with HDTV Link Ver.5. HDTV Link Ver.5 is the newest version and is also compatible with existing HDTV Link compatible devices. ● Always use the genuine Leica HDMI mini cable (available as accessory →9). ● Cables that do not comply with HDMI standards will not work.

  • Page 158: Turn On The Camera

    Playing back on a TV Preparation: Set [HDTV Link] to [ON] (→59). Connect the camera to a HDTV Link (HDMI)-compatible television with the HDMI mini cable (available as accessory →9) (→155) Turn on the camera Set the REC/PLAY switch to Proceed with the operation while referring to what is displayed on the TV screen •...

  • Page 159: Playing Back 3D Still Pictures

    Playing back on a TV Playing back 3D still pictures If you connect this camera to a 3D-capable TV and play back still pictures that you recorded in 3D, you can enjoy impressive 3D still pictures on the TV. If a 3D-capable TV has an SD card slot, you can play back 3D still pictures that you recorded by inserting the card into the slot.
  • Page 160 Playing back on a TV ■ To switch the playback method for the still pictures recorded in 3D Select the picture recorded in 3D Select [2D/3D Settings] in the [Playback Mode] menu and then press [MENU/SET] (→111) • The playback mode will switch to 3D if it is playing back in 2D (conventional image), or it will switch to 2D if it is playing back in 3D.

  • Page 161: Copying The Recorded Still And Motion Pictures

    To recorder’s input socket playback on the camera. ● Always use the genuine Leica AV cable (included in scope of delivery →9). ● When using a TV with a 4:3 aspect ratio, always change the camera’s [TV Aspect] setting (→59) to [4:3] before dubbing. Motion pictures copied in the [16:9] setting will appear vertically stretched when viewed on a 4:3 TV screen.

  • Page 162: Copying The Recorded Image Data To A Computer With The Supplied Software

    Basic Instructions. Register your camera on the Leica Camera AG homepage a. Open an account at http://owners.leica-camera.com. As a result, you will receive access to the “Owners area”. b. Register your camera at “My products”. Do so by following the respective instructions.

  • Page 163: Using With Your Pc

    Using with your PC Still/motion pictures can be copied from the camera to your computer by connecting the two. • Some computers can read directly from the camera’s memory card. For details, see the instructions for your computer. • If your computer does not support SDXC Memory Cards a message will be displayed requesting you to format the card.

  • Page 164: Copying Still And Motion Pictures Recorded In [Mp4] And [High Speed Video] Scene Mode (Except Avchd Motion Pictures)

    Using with your PC Copying still and motion pictures recorded in [MP4] and [High Speed Video] Scene Mode (except AVCHD motion pictures) Preparation: Make sure the plug is aligned correctly and that it is inserted straight. • Charge the battery (Otherwise the connectors may be bent out of shape sufficiently.
  • Page 165 999LEICA ● MISC (DPOF files, Favorite) ∗ ∗ Drives are displayed on AD_LEICA the desktop. (Displayed as “LEICA”, ∗ PRIVATE “NO_NAME”, or “Untitled”.) AVCHD (Motion pictures in AVCHD) MAP_DATA (Map data) ∗ New folders are created in the following cases: •...

  • Page 166: Printing

    Printing You can connect directly to a PictBridge-compatible printer for printing. • Some printers can print directly from the camera’s memory card. For details, see the instructions for your printer. Preparation: • Do not disconnect the USB connection cable when the cable disconnection icon is displayed •...
  • Page 167 Printing ● Do not use any other USB connection cables except the supplied one. ● Disconnect the USB connection cable after printing. ● Turn off the power before inserting or removing memory cards. ● When the battery begins to run out during communication, a warning beep sounds. Cancel printing and disconnect USB connection cable.

  • Page 168: Printing Multiple Pictures

    Printing Printing multiple pictures Use the respective cursor buttons to select [Multi Print] in step (→166) Use the respective cursor buttons to select the desired mode and then press [MENU/SET] • [Multi Select]: Scroll between the pictures with the respective cursor buttons, select the pictures to print with the [DISP.] button.

  • Page 169: Making Print Settings On The Camera

    Printing Making print settings on the camera Make the settings before selecting [Print start]. Use the respective cursor buttons to select the mode and press [MENU/SET] Mode Settings [Print with [ON]/[OFF] Date] [Num.of Set the number (up to 999 pictures) prints] [Paper Size] When...

  • Page 170: List Of Monitor Displays

    List of monitor displays The screen shown here is only an example. The actual display may vary. • Press the [DISP.] button to change displays. ■ In recording 1 Recording Mode (→25) 6 Touch AF/AE function canceled (→30) 2 Backlight Compensation (→32, 34) 7 Histogram (→62) Recording quality (→107) 8 Touch shutter release (→29)
  • Page 171 List of monitor displays The screen shown here is only an example. The actual display may vary. • Press the [DISP.] button to change displays. ■ In recording ∗ 12 Elapsed recording time 17 Custom Set (→85) (→37) [GPS Area Select] (→135) 18 Focus (→28) 13 Self-timer Mode (→70) 19 Save destination (→20)
  • Page 172 List of monitor displays The screen shown here is only an example. The actual display may vary. • Press the [DISP.] button to change displays. ■ In playback 1 Playback Mode (→111) 6 Print settings (→123) 2 Protected picture (→124) 7 Histogram (→62) Favorites (→122) 8 Video Divide (→48)
  • Page 173 List of monitor displays The screen shown here is only an example. The actual display may vary. • Press the [DISP.] button to change displays. ■ In playback 10 Recording date/time 14 Series exposure information is being World time (→93) retrieved (→109) ∗...

  • Page 174: Message Displays

    ● The lens is not working correctly. → Turn the camera off and back on again. (Consult your Leica dealer or the nearest Leica Customer Care center if the message is still displayed) [Some pictures cannot be copied] [Copy could not be completed] ●...
  • Page 175 → The message disappears when the cable is also connected to another device. [This battery cannot be used] ● Use a genuine Leica battery. ● The battery cannot be recognized as its terminals are dirty. → Wipe any dirt away from the battery terminal.
  • Page 176 Q&A Troubleshooting Try checking these items (→176 - 183) first. If the problem persists, performing [Reset] in the [Setup] menu may resolve the issue (→58). (Note that except for some items such as [Clock Set], all settings are returned to their values at the time of purchase.) Battery, power The charging lamp turns off before the battery is fully charged.

  • Page 177: Q&A Troubleshooting

    (→138) The detailed maps are not displayed. ● Use the “LEICA Map Tool” software on the DVD (supplied) to copy map data from the DVD. (→149) Some place names are not displayed. ● Detailed maps are displayed when you copy map data from the DVD (supplied). (→149) (Note, however, that not all place names are stored in the DVD.)
  • Page 178 Q&A Troubleshooting Recording (continued) Several pictures are taken when I press the shutter release button just once. ● The camera is set to use [Auto Bracket] or [Burst]. The focus setting is not correct. ● The mode set is not appropriate for the distance to the subject. (The focus range varies according to recording mode.) ●...
  • Page 179 Q&A Troubleshooting Recording (continued) Motion picture recording stops midway. ● With camera models 18 176 / 18 177 If [Rec Quality] of [AVCHD] motion pictures is set to [GPH], [PSH], [GFS] or [FSH], you can continuously record a motion picture for up to 29 minutes . (→107) You can continuously record a motion picture in [MP4] for up to 29 minutes or approx.
  • Page 180 Q&A Troubleshooting Flash No flash is emitted. ● The flash is set to [Forced Flash Off] (→66). ● The flash becomes unavailable in the following cases : • [Auto Bracket] • [Burst] (However, when [Flash Burst] is selected, the flash is fixed to [Forced Flash On].) •...
  • Page 181 Q&A Troubleshooting Playback (continued) Red parts are rendered black in the recorded pictures. ● When digital red-eye correction ( ) is operating, if a subject is recorded that has skin- colored areas with red areas inside, the digital red-eye correction function may blacken the red areas.
  • Page 182 Q&A Troubleshooting TV, computer, printer (continued) The computer does not recognize the card (it only reads the built-in memory). ● Disconnect the USB connection cable (supplied) and reconnect with a card in place. The computer does not recognize the card. (When using SDXC Memory Cards) →...
  • Page 183 Q&A Troubleshooting Others The menu is not displayed in the desired language. ● Change the [Language] setting (→61). The camera rattles if shaken. ● This sound is made by the lens movement and is not a fault. The red lamp is illuminated when pressing the shutter release button halfway in dark locations.

  • Page 184: Usage Cautions And Notes

    Usage cautions and notes When in use ● The camera may become warm if used for long periods of time, but this is not a fault. ● Keep the camera as far away as possible from electromagnetic equipment (such as microwave ovens, TVs, video games etc.).
  • Page 185 Usage cautions and notes Memory cards ● To prevent damage to cards and data • Avoid high temperatures, direct sunlight, electromagnetic radiation, and static electricity. • Do not bend, drop, or expose to strong impacts. • Do not touch terminals on reverse of card or allow them to become dirty or wet. ●...
  • Page 186 Usage cautions and notes About the charger (supplied) ● Keep it at least 1 m (3.3 feet) away from an AM radio (otherwise, it might cause radio interference). ● The charger may generate whirring sounds when it is being used. This is not a malfunction. ●...
  • Page 187 • Data containing personal information can be altered or lost due to malfunction, static electricity, accidents, breakdowns, repairs, or other operations. Leica Camera AG will not be liable for any damage that occurs, direct or indirect, as a result of the alteration or loss of data containing personal information.

  • Page 188: Licence Agreement For Place Name And Map Data

    Except where you have been specifically are stored in this product. licensed to do so by Leica Camera AG, and without limiting the preceding paragraph, you may not (a) use this Data Licence Agreement for...
  • Page 189 LEICA CAMERA AG AND ITS you agree to use it at your own risk. LICENSORS (INCLUDING THEIR Leica Camera AG and its licensors (and LICENSORS AND SUPPLIERS) SHALL their licensors and suppliers) make no NOT BE LIABLE TO YOU: IN RESPECT...
  • Page 190 Usage cautions and notes Export Control. Leica Camera AG shall not export from anywhere any part of the Data or any direct product thereof except in compliance with, and with all licenses and approvals required under, applicable export laws, rules and regulations, including but not...
  • Page 191 Usage cautions and notes About Location Information, Place Name Information, and Maps About the geographical coordinate system The latitude and longitude standard (geographical coordinate system) recorded with this camera is WGS84. Mapple Digital Map Data These maps were prepared using the following maps of the Geospatial Information Authority of Japan (GSI), with the approval of the Director General of GSI: 1:25,000 scale topographic maps, 1:200,000 scale regional maps, 1:1,000,000 scale maps of Japan, and 1:500,000 scale district maps.
  • Page 192 Usage cautions and notes Territory Notice Australia © Hema Maps Pty. Ltd, 2011. Copyright. Based on data provided under license from PSMA Australia Limited (www.psma.com.au). Product incorporates data which is © 2011 Telstra Corporation Limited, GM Holden Limited, Intelematics Australia Pty Ltd, NAVTEQ International LLC, Sentinel Content Pty Limited and Continental Pty Ltd.
  • Page 193 Usage cautions and notes Territory Notice Sri Lanka This product incorporates original source digital data obtained from the Survey Department of Sri Lanka © 2009 Survey Department of Sri Lanka The data has been used with the permission of the Survey Department of Sri Lanka Sweden “Based upon electronic data ©...
  • Page 194 Usage cautions and notes ■ Landmark types Although approx. 1,000,000 landmarks are registered in the built-in memory, there are also some unregistered landmarks. (The registered information is current as of December 2011 and will not be updated.) • It differs from that registered on our GPS-equipped models before 2011. Botanical garden Aquarium Amusement park...

  • Page 195: Leica Service Addresses

    Leica Academy As well as outstanding high-performance products for taking and viewing photographs, for many years we have also been offering the special services of the Leica Akademie, with practical seminars and training courses, which are intended to share our knowledge about the world of photography, projection and magnification with both beginners and advanced photo graphic enthusiasts.
  • Page 196 They are also your contact if you need advice concerning an acquisition or if you would like us to send you instructions. Alternatively, you can also send us your questions through the contact form on the Leica Camera AG homepage (see above).
  • Page 197 • This product uses “DynaFont” from DynaComware Corporation. DynaFont is a registered trademark of DynaComware Taiwan Inc. • Leica is a registered trademark of Leica Microsystems IR GmbH. • Elmar is a registered trademark of Leica Camera AG. • Adobe Photoshop Elements and Adobe Premiere Elements are registered trademarks of Adobe Systems Incorporated.
  • Page 198 Leica Camera AG / Oskar-Barnack-Straße 11 / D-35606 SOLMS / DEUTSCHLAND Telefon +49 (0) 6442-208-0 / Telefax +49 (0) 6442-208-333 www.leica-camera.com...

This manual is also suitable for:

V-lux 40

Table of Contents
