4.2 Camera Connection

1) Connect the camera to a switch using an Ethernet cable.
2) Connect supplied I/O cable to the camera.
3) To attach external devices, such as sensors and alarms, connect them to
the extension I/O terminal block.
Optional Dome Camera Accessories
Power Adapter
77H07-A1015 (Input: 100~115 VAC / Output: 24 VAC 36 VA)
77H07-A2015 (Input: 220~230 VAC / Output: 24 VAC 36 VA)
NOTE: When wiring, make sure the G / Y wire (Ground) inserted
into the mid-pin of the terminal block.
11
