User Manual
36x Outdoor Speed Dome
Network Camera
OSD-040 36x Series
Quick Installation Guide
Quality Service Group
Advertisement
Related Manuals for Brickcom OSD-040 36x Series
Summary of Contents for Brickcom OSD-040 36x Series
-
Page 1: Quick Installation Guide
36x Outdoor Speed Dome Network Camera OSD-040 36x Series Quick Installation Guide Quality Service Group... - Page 2 Read Before You Use 1. Power off the camera device immediately if it starts smoking or smells unusual. 2. Power off the camera device immediately if the camera is exposed to rain or liquid. 3. Do not set the camera device near any heat sources.
- Page 3 6. Do not set the camera device in any wet and humid environments. 7. Do not set the camera device on unsteady surfaces. 8. Do not attempt to dismantle the camera device. 9. Do not drop or hit the camera device. 10.
- Page 4 1. Check Package Contents a. Speed Dome Camera b. Mount Kit c. I/O Cable d. Waterproof Rubber e. Warranty Card f. M5 Screw g. Dome Cover h. Lubricant i. Product CD j. Screw for Dome Cover k. Easy Installation Guide...
- Page 5 2. Device Description <Bottom View> Power LED Link LED Ethernet RJ45 10/100 Socket Reset Button Safety Wire Hook I/O Cable Connector <I/O Cable> Extension I/O Terminal Block AC Power Input Video Out Audio Out(Pink) Microphone/Line In(Green) <Dimension> Mount Holder...
- Page 6 3. Camera Connection 1. Connect the camera to a switch using an Ethernet cable. 2. Connect supplied I/O cable to the camera. 3. To attach external devices, such as sensors and alarms, connect them to the extension I/O terminal block.
- Page 7 4. Hardware Installation Before Installation The SD-040 36x is supplied with a dome cover to protect the camera unit. Before installation, follow these instructions to attach the dome cover and remove the mount holder. 1. Unpack the dome package and take out the Dome body. 2.
- Page 8 Apply lubricant to the Dome cover’s water-proof rubber to make the installation process smoother. NOTE: The tiny protrusion on the dome cover must align with one of the four holes on the dome body. Attach the Dome cover to the Dome body by gently pressing down on the sides of the Dome cover with both hands.
- Page 9 Install Camera with Mount Kit 1. Make a cable entry hole on the wall/ ceiling to insert the cable(s). 2. Mount the Speed Dome camera according to the “Speed Dome Mounting Accessories Installation Guide”. 3. Attach the waterproof rubber to the selected mount kit. 4.
- Page 10 1. Insert the Installation CD into the CD-ROM driver. Run Auto-Run Tool directly from the CD-ROM to start the installation. When installing the Brickcom software kit for the first time, select a desired language for the interface. The available languages are listed in the scroll box. Click <Install>...
- Page 11 2. To launch EasyConfig or PC-NVR Standard, select the application and click <Finish>. When launching the PC-NVR program, please refer to the PC-NVR user manual.
- Page 12 If Custom Setup type was used in the software installation and an EasyConfig icon was not installed on the desktop, the program will be installed under C:\Program Files\Brickcom\EasyConfig unless the program was saved to a preferred directory. 1. Click <Start> to continue. The program will automatically search for the camera in the intranet.
- Page 14 2. Select either “Simple Mode” or “Professional Mode” to obtain the camera’s IP settings. If “Simple Mode” is selected, EasyConfig will set up the connection automatically. If “Professional Mode” is selected, the user will need to configure the IP settings manually. 3.
- Page 15 4. Enter the username and password of the camera. For first time use, the default username and password are “admin/admin.” 5. For configuring the IP address settings, select either <Settings remain the same>, <Automatically obtain an IP Address (DHCP)> or <Set IP Address configuration manually>. The DHCP setting is recommended.
- Page 16 a. If <Set IP Address configuration manually> is selected, the following pages will be displayed.
- Page 17 *If desired, click <Skip> to skip this setting. EasyLink is a unique Brickcom function which allows users to assign a unique EasyLink name to their network camera’s IP address. There is no need to configure the router to open up ports or remember hard-to-memorize IP addresses.
- Page 18 7. When the IP address settings have been configured, the screen will either display a successful or failed connection message. If the connection failed, either try again or quit the installation. a. If “DHCP IP address settings” was selected, the failure page will be displayed as below: b.
- Page 19 c. If the connection was successful, the user will see the message: “Congratulations. The installation of the camera is complete.” When this window is displayed, click <PC-NVR> to start the PC-NVR program, <Live View> to view the live video from the connected IP camera, or <X>...
