Chapter 4 - Installation
4.1 Hardware Installation
A. Before Installation
The OSD-200A 20xp is supplied with a dome cover to protect the
camera unit. Before installation, follow these instructions to attach the
dome cover and the mount holder.
1) Pull out the Dome cover and take out the mounting tape; and then
apply lubricant to the Dome cover's water-proof rubber to make the
installation process smoother.
2) Attach the Dome cover to the Dome body by gently pressing down
on the sides of the Dome cover with both hands.
NOTE - The tiny protrusion on the dome cover must align with
one of the four holes on the dome body.
NOTE - DO NOT press the cover from the top as this may
cause damage to the Dome body.
8
