Chapter 7 - Installation
7.1 Hardware Installation
WARNING - Do not mount the camera on a soft material. The camera may fall
and be damaged.
A. Wall Installation
(1) Drill three holes into the wall. (2) Hammer the supplied plastic anchors into the three
holes. (3) Use a screwdriver and the supplied screws to secure the camera to the wall.
7.2 Camera Connection
The Bullet Series is DC12V and PoE compliant, so there are two options for connecting
the camera to a power and Ethernet source. The camera can either be connected to a
PoE-enabled switch or a non-PoE switch.
a. If using a PoE-enabled switch:
Use a single Ethernet cable to connect the camera to the PoE-enabled switch.
10
