- Page 1 36x Outdoor Speed Dome Network Camera OSD-040 36x Series Mounting Accessories Installation Guide Quality Service Group...
- Page 2 Speed Dome Package Content a. Speed Dome Camera b. Mount Kit c. I/O Cable d. Waterproof Rubber e. Warranty Card f. M5 Screw g. Dome Cover h. Lubricant i. Product CD j. Screw for Dome Cover k. Easy Installation Guide...
- Page 3 1. Ceiling Mounting with Straight Tube The Straight Tube is available in different length: 25 cm and 30 cm. Follow the steps to mount the Speed Dome Camera with the Straight Tube. Ensure that the ceiling can support the weight of the Speed Dome Camera and Straight Tube.
- Page 4 Wall Mounting 2.1 Mini/Standard Pendent Moun Follow the steps below to mount the Speed Dome Camera with the Mini/Standard Pendent Mount. Make a cable entry hole on the wall to insert the cables through the bracket or push up the Cable Entry Board on the Mini/Standard Pendent Mount’s Mounting Plate to place the cables.
- Page 5 Thread the cable(s) through the supplied camera top holder and join the holder to the Mini/Standard Pendent Mount with the supplied screws and washers. Then adjust the Waterproof Rubber over the joint. Connect the Ethernet and I/O cables and hook the safety wired to the camera.
- Page 6 2.2 Wall Box Mounting Follow the steps to mount the Dome Camera with the Standard/Mini Pendent Mount and Wall Box Mount. Make a cable entry hole on the wall to insert the cable(s). Attach the Wall Box Mounting to the wall with proper screws and screw anchors.
- Page 7 3. Corner Mount 3.1 Corner Mounting Plate Follow the steps below to mount the Speed Dome Camera with the Corner mounting Plate and Standard/Mini Pendent Mount. Make a cable entry hole on the wall to insert the cable(s). Attach the Corner Mounting Plate to the corner of the wall with the proper screws and screw anchors.
- Page 8 3.2 Corner Box Mounting Follow the steps below to mount the Speed Dome Camera with the Corner Box and Standard/Mini Pendent Mount. Make a cable entry hole on the wall to insert the cable(s). Attach the Corner Box to the corner of the wall with proper screws and screw anchors.
- Page 9 4. Pole Mount 4.1 Pole Direct Mounting Follow the steps below to mount the Speed Dome Camera with the Pole Direct Mount and Standard/Mini Pendent Mount. Fasten the Pole Direct Mounting onto a pole using the stainless straps. Run the cable(s) through the hole on the Pole Direct Mount with the I/O Cable’s connector coming out.
- Page 10 4.2 Pole Box Mounting Follow the steps below to mount the Speed Dome Camera with the Pole Box Mount and Standard/Mini Pendent Mount. Fasten the Pole Direct Mounting onto a pole using the stainless straps. Run the cable(s) through the hole on the Pole Box Mount with the I/O Cable’s connector coming out.
