Available settings for the Modbus-TCP network.
Setting
IP address
Subnet mask
Gateway
DHCP
Modbus connection timeout
Process active timeout
Ethernet settings 1
Ethernet settings 2
Word order
When Modbus (Network 2)
error
I/O mapped control/status word If enabled, the control/status word is mapped to the output/input area respectively. See
I/O mapped live list
Anybus X-gateway for Modbus-TCP - Modbus-TCP
Doc.Rev. 1.00
Description
If not set by Network 1 or DHCP, set these values manually
(Disable DHCP to make the fields editable)
Enabled by default. When enabled, the X-gateway can obtain the TCP/IP settings
dynamically from the DHCP server of the Modbus-TCP network (Network 1)
This value specifies how long a Modbus-TCP connection may be idle before it is closed
by the X-gateway (in seconds)
Default value: 0 (disabled)
This value specifies how long the X-gateway shall stay in the 'I/O data exchanged'-state
after receiving a Modbus-TCP request (in milliseconds)
Default value: 0 (disabled)
Default value: Auto (value set from Network 1)
Values: Little endian (default) or big endian
The "Freeze data to master" option instructs the X-gateway to keep sending the latest
received data from the Modbus-TCP network to the Modbus-TCP master
The "Clear data to master" option instructs the X-gateway to clear the input data area
and send only zeros to the Modbus-TCP master
"Control/Status Word" on page 13
If enabled, the live list is mapped to the input area. See "Live List" on page 14
