- Page 2 Anybus ® Wireless Bolt ™ INSTALLATION GUIDE SCM-1202-006/SP2139 1.7 ENGLISH...
-
Page 3: Important User Information
AB of any inaccuracies or omissions. The data and illustrations found in this document are not binding. We, HMS Industrial Networks AB, reserve the right to modify our products in line with our policy of continuous product development. The information in this document is subject to change without notice and should not be considered as a commitment by HMS Industrial Networks AB. - Page 4 Description 3 (16) Description This document describes how to install Anybus Wireless Bolt and set up a basic configuration. For additional documentation and technical support, please visit the Anybus support website www.anybus.com/support. Anybus Wireless Bolt provides wireless communication capability over WLAN and/or Bluetooth ®...
-
Page 5: Installation
Installation 4 (16) Installation Anybus Wireless Bolt should be mounted vertically (logo facing upwards) for best performance due to the characteristics of the internal antenna. For optimal reception, wireless devices should be placed with a line of sight be- tween them clear of obstructions. A minimum distance of 50 cm between the de- vices should be observed to avoid interference. - Page 6 Installation 5 (16) Mechanical Installation Anybus Wireless Bolt is intended to be mounted on top of a machine or cabinet through an M50 (50.5 mm) hole using the included sealing ring and nut. Tightening torque: 5 Nm ±10 % Make sure that the sealing ring is correctly placed in the circular groove in the top part of the housing before tightening the nut.
- Page 7 Installation 6 (16) Connector Pinning Note the location of the RESET button when the connector is attached to the Wireless Bolt. Pin 1 will be the pin closest to the button. Description Name Power 9–30 VDC Power Ground Digital input (9–30 VDC) DI_GND Digital input ground ETN_RD+...
- Page 8 7 (16) Cabling To make an Ethernet connector cable for the Anybus Wireless Bolt: Cut off one of the connectors on a standard Cat5e or Cat6 Ethernet cable. Strip off about 40 mm (1½ inch) of the cable jacket and untwist the orange, orange/white, green and green/white wires.
-
Page 9: The Web Interface
Configuration 8 (16) Configuration Anybus Wireless Bolt can be configured either by setting individual parameters in the web interface or by using a pre-configured Easy Config mode. Advanced configuration can be carried out by issuing AT (Hayes) commands in the AT Commands tab in the web interface, or over Telnet to port 8080. A list of the supported AT commands is available at www.anybus.com/support. -
Page 11: Factory Reset
Factory Reset 10 (16) Factory Reset Anybus Wireless Bolt can be reset to the factory default settings using either of the following methods: • Press and hold the Reset Button for >10 seconds and then release it • Execute Easy Config Mode 2 through the web interface •... -
Page 12: Reset Button
Factory Reset 11 (16) Reset Button The reset button is located on the bottom of the unit next to the connector. • Press and hold the button for >10 seconds and then release it to reset to the factory default settings when the unit is powered on. •... -
Page 13: Configuration Examples
Configuration Examples 12 (16) Configuration Examples For more configuration examples, see the Anybus Wireless Bolt User Manual. • All the examples start out from the factory default settings. • Settings not mentioned should be left at their default values. EXAMPLE 1: Setting up a network bridge with Easy Config This example describes how to connect two Ethernet network segments over WLAN or Bluetooth using two Wireless Bolts. - Page 14 Configuration Examples 13 (16) EXAMPLE 2: Accessing a PLC from a handheld device over WLAN This example describes how to access the web interface of a PLC using a tablet or smartphone over WLAN. A: The PLC or network has an active DHCP server In Network Settings, select IP Assignment: Dynamic (DHCP) and contin- ue to step 3 below.
-
Page 15: Technical Data
Wave shape: half sine, Number of shocks: ±3 in each axes, Mode: In operation, Axes ± X,Y,Z, Acceleration: 30 m/s , Duration: 11 ms Humidity EN 600068-2-78: Damp heat, +40 °C, 93 % humidity for 4 days Certifications See Anybus Wireless Bolt Compliance Sheet Anybus ® Wireless Bolt ™ Installation Guide... - Page 16 Technical Data 15 (16) Host Communication Ethernet interface 10/100BASE-T, auto MDI/MDIX cross-over detection Supported protocols: IP, TCP, UDP, HTTP, LLDP, ARP, DHCP Client/Server, DNS support, PROFINET IO, EtherNet/IP, Modbus-TCP Serial interface Isolated RS-232/485 (max. 1 Mbit/s) CAN interface Isolated CAN (max. 1 Mbit/s) Digital input Max 3 m signal cable length WLAN Specifications...
