2.6 Control/Status Word
The Control/Status word is optional and disabled by default. It can be enabled/disabled when config-
uring the Modbus-TCP network via the configuration web pages. See "Modbus-TCP (Network 1 Server
Interface)" on page 35.
The Control word is a 16-bit word (uint16) used by Network 1 to control the Anybus X-gateway and
subsequently also Network 2. If enabled, it is always mapped to the first two bytes of the output data
area.
Bit
Value
0 (Least signifi-
0
cant bit)
1
1
0
1
2-7
Set to zero
8-15
Set to zero
The Status word is a 16-bit word used by the X-gateway to report its current actual status to Network 1.
If enabled, it is mapped to the first two bytes of the input data area.
Bit
Value
0 (Least signifi-
0
cant bit)
1
1-7
(reserved)
8-15
(reserved)
Anybus X-gateway for Modbus-TCP - Modbus-TCP
Doc.Rev. 1.00
Anybus X-gateway for Modbus-TCP - Modbus-TCP 13
Description
Puts the X-gateway in idle state
Puts the X-gateway in run state
-
Reboot the X-gateway
Unused
Unused
Description
The X-gateway is in idle state
The X-gateway is in run state
Unused
Unused
Doc.Id. SCM-1200-114
