Flexiblelom Option - HP ProLiant DL160 Gen8 User Manual

Connect the front video adapter to the video device.
2.

FlexibleLOM option

WARNING:
remove the power cord to remove power from the server. The front panel Power On/Standby
button does not completely shut off system power. Portions of the power supply and some internal
circuitry remain active until AC power is removed.
If installed, remove the rack bezel (on page 59).
1.
Power down the server (on page 17).
2.
Remove all power:
3.
Disconnect each power cord from the power source.
a.
Disconnect each power cord from the server.
b.
Remove any attached network cables.
4.
Extend the server from the rack (on page 17).
5.
Remove the access panel (on page 19).
6.
Remove the processor air baffle (on page 19).
7.
Remove the PCI riser cage (on page 20).
8.
Loosen the thumbscrew.
9.
To reduce the risk of personal injury, electric shock, or damage to the equipment,
Hardware options installation 54
