Rated input current
Rated input power
BTUs per hour
Power supply output
Rated steady-state power
Maximum peak power
CAUTION:
DC supply circuit to the earthing conductor at the equipment. See installation instructions.
CAUTION:
earthing conductor at the server equipment, the following conditions must be met:
• This equipment must be connected directly to the DC supply system earthing electrode
conductor or to a bonding jumper from an earthing terminal bar or bus to which the DC supply
system earthing electrode conductor is connected.
• This equipment should be located in the same immediate area (such as adjacent cabinets) as
any other equipment that has a connection between the earthed conductor of the same DC
supply circuit and the earthing conductor, and also the point of earthing of the DC system. The
DC system should be earthed elsewhere.
The DC supply source is to be located within the same premises as the equipment.
•
Switching or disconnecting devices should not be in the earthed circuit conductor between the
•
DC source and the point of connection of the earthing electrode conductor.
CAUTION:
This equipment must be installed by trained service personnel, as defined by the NEC and IEC
•
60950-1, Second Edition, the standard for Safety of Information Technology Equipment.
Connect the equipment to a reliably grounded safety extra low voltage (SELV) source. An SELV
•
source is a secondary circuit that is designed so normal and single fault conditions do not
cause the voltages to exceed a safe level (60 V direct current).
The branch circuit overcurrent protection must be rated 20A.
•

Power supply calculations

For power supply specifications and calculators to determine electrical and heat loading for the server, refer
to the HP Enterprise Configurator website (http://h30099.www3.hp.com/configurator/).
10 A to 5 A
556 W at 115V AC input
542 W at 230V AC input
1917 at 100 V AC
1898 at 115 V AC
1856 at 200 V AC
1850 at 230 V AC
500 W at 100V to 120V AC input
500 W at 200V to 240V AC input
500 W at 100V to 120V AC input
500 W at 200V to 240V AC input
This equipment is designed to permit the connection of the earthed conductor of the
If the DC connection between the earthed conductor of the DC supply circuit and the
To reduce the risk of electric shock or energy hazards:
Specifications 96
