Specifications; Environmental Specifications; Server Specifications; Power Supply Specifications - HP ProLiant DL160 Gen8 User Manual

Specifications

Environmental specifications

Specification
Temperature range*
Operating
Shipping
Maximum wet bulb temperature
Relative humidity
(noncondensing)**
Operating
Non-operating
* All temperature ratings shown are for sea level. An altitude derating of 1°C per 300 m (1.8°F per 1,000 ft) to 3048
m (10,000 ft) is applicable. No direct sunlight allowed.
** Storage maximum humidity of 95% is based on a maximum temperature of 45°C (113°F). Altitude maximum for
storage corresponds to a pressure minimum of 70 kPa.

Server specifications

Specification
Height
Depth (chassis with SFF drive
cage)
Depth (chassis with LFF drive cage) 75.0 cm (29.5 in)
Width
Weight (maximum SFF: two
processors, one power supply,
eight drives)
Weight (maximum LFF: two
processors, one power supply,
four drives)

Power supply specifications

Depending on installed options, the server is configured with one of the following power supplies:
•
HP 460 W CS Power Supply (94%) specifications
•
HP 750 W CS Power Supply (94%) specifications
•
HP 500 W Multi-output Power Supply specifications
Value
10°C to 35°C (50°F to 95°F)
-40°C to 70°C (-40°F to 158°F)
28°C (82.4°F)
10% to 90%
5% to 95%
Value
4.32 cm (1.70 in)
69.9 cm (27.5 in)
43.46 cm (17.11 in)
16.9 kg (37.25 lb)
17.6 kg (38.80 lb)
Specifications 94
