Remove the adhesive stickers from the VGA cable clips, and then attach the clips onto the fan cage.
7.
Route the cable through the cable clips, and then connect then cable to the VGA card and power supply
8.
cable.
Install the processor air baffle.
9.
Install the access panel.
10.
Slide the server into the rack.
11.
Connect each power cord to the server.
12.
Connect each power cord to the power source.
13.
Power up the server (on page 17).
14.
If removed, install the rack bezel (on page 60).
15.

Mini-SAS cable option

The server supports the 700 mm mini-SAS cable option.
("Install the processor air baffle" on page 20)
Hardware options installation 61
