devices to run simultaneously on a single computer, with some peripheral
acting as additional plug-in sites or hubs.
S/PDIF
S/PDIF output for carrying digital audio signals out to the device.
eSATA/USB (combo)
This provides eSATA and USB connectivity as a combo connector.
3G External Antenna
Spared hole on the casing for connecting 3G external antenna
CF Slot
CompactFlash Card Slot
Phone Jack
Audio Out
The stereo headphone jack is used to connect the system's audio out signal to
amplified speakers or headphones.
MIC-IN
The microphone jack is designed to connect the microphone used for video
conferencing, voice narrations, or simple audio recordings.
Line-IN
The Line-in jack is designed to take input from a higher-powered sound source.
This connector do not support hot-swapping. Users should not connect or
disconnect their eSATA/USB (combo) & CF devices from PC when the
system is Working.
QDSP-2060 User's Manual
CAUTION
17
Chapter 1
