3: System Operation and Monitoring

Power Supply LED

20
There is a single bi-color LED (green/amber) to indicate the power supply status.
describes the different states of the LED.
Table 3-4
Power Supply LED States
LED State Power Supply (PS) State
Off No AC power to any PS.
Green Output on and Ok.
Green, 1Hz blink AC present (only 12VSB on). PS off or PS in cold redundant state.
Green, 2Hz blink PS firmware updating.
Amber – PS critical event causing a shutdown/failure (OCP, OVP, fan failure)
– AC cord unplugged or AC power lost. A second power supply in
parallel still has AC input power.
Amber, 1Hz blink PS warning events where the power supply continues to operate (high
temperature, high power, high current, slow fan).
Table 3-4
