Installing the Power Supply Modules

007-5900-001
To install the power supply modules, use the following steps:
1. Align and slide the module into the power supply cage as shown in
2. Push the module along the rail until the latch locks in position with a click.
3. Repeat steps 1 and 2 to install the second module.
Figure 4-8
Installing a Power Supply Module
Replacing the Power Supply Modules
Figure 4-8.
31
