System Operation and Monitoring

Figure 3-1 shows the control panel at the top right of the front panel. There are several LEDs on
the control panel as well as others on the hard drive carriers and power supplies. The LEDs keep
you constantly informed of the overall status of the system as well as the activity and health of
specific components. There are also control buttons on the control panel. This chapter describes
the buttons and LEDs.
Figure 3-1
Front Control Panel
