3: System Operation and Monitoring

Front Panel Controls and LEDs

16
The control panel contains control buttons and status LEDs.
a control panel.
Figure 3-2
Control Panel Components
Table 3-1 describes the control panel components and their functions.
Table 3-1
Control Panel Components and Functions
Label Button/LED
A System ID
Button with LED
B NMI Button
Network
C,J Link/Activity
LEDs
D
E System Cold
Reset Button
Color Condition Function
Blue On Highlights targeted system. Can be activated by the
button or software.
Used for diagnostics.
On No access to LAN link.
Green Blink LAN activity.
Off No link.
Not used.
When pressed, this button reboots and re-intializes
the system.
Figure 3-2 shows the components of
