• — Opens the Names for Presets window, which contains a list of all
Name Presets
the room and global presets that you have defined.
1.
Select a preset from the list and enter a name for it in the text box at the top of
the screen.
2.
Click Take to confirm the name.
Figure 91. Names for Presets Window
NOTES: Preset names are limited to 12 upper- and lowercase alphanumeric
characters, {
The following characters are invalid or not recommended in preset names:
+ ~ , @ = ` [ ] { } < > ' ' " " ; : | \
•
Show RS-232 strings
configuration. You can refer to these for SIS programming (see the
and Control section, beginning on page 49, for information on entering SIS
commands).
Figure 92. RS-232 Program Strings Window
DXP DVI, DXP DVI Pro, and DXP HDMI Series • Matrix Software
}, and the
and
space _ : =
— Displays the ASCII commands that are used by the current
characters.
/
and .
?
SIS Configuration
93
