Chapter 8—Intermec Shell Startup Program
Intermec Shell v8.0 Overview
POWER ON
ENTER=SHELL
5 sec. v.8.0
ENTER=SHELL
4 sec. v.8.0
ENTER=SHELL
3 sec. v.8.0
ENTER=SHELL
2 sec. v.8.0
ENTER=SHELL
1 sec. v.8.0
Last selected
application is started
Default:
Fingerprint 8.10 w. std I/O = "auto"
Legend:
Return to previous menu.
Proceed to next menu.
Accept displayed option
and proceed, or
execute displayed option.
Perform a Testfeed
anywhere in Intermec Shell.
Enter the Setup Mode
from anywhere
in Intermec Shell.
82 Intermec EasyCoder PF4i Compact Industrial—User's Guide (Fingerprint)
SHELL
SEL. APPLICATION
SEL. APPLICATION
CURRENT APPL.
SEL. APPLICATION
Fingerprint 8.10
SEL. APPLICATION
Direct Protocol
Optional application
programs
SEL.APPL rom:
LINE_AXP.PRG
SHELL SETUP:
SETUP SER-COM,UART1
SHELL
Prints a list of current setup values (test label "Setup Info").
PRINT SETUP
Performs a Testfeed (feeds out a number of blank copies
SHELL
while autoadjusting the label stop sensor).
TESTFEED
SHELL Prints test labels "Diamonds", "Chess", "Bar Codes #1", and "Bar Codes #2" in a loop
Press Enter for each new label.
TEST LABEL
SHELL
ARE YOU SURE?
DEFAULT SETUP
YES=ENTER/NO=ESC
UPDATE:
SHELL
COMPACT FLASH?
SOFTWARE UPDATE
SHELL UPDATE:
FIRMWARE?
REBOOT
Restarts the printer (same as power off/on)
Last selected application is started
Note: Dotted channels are only shown if
the corresponding optional interface pcb
is fitted.
STD I/O CHANNEL
auto
STD I/O CHANNEL
uart1:
STD I/O CHANNEL
uart2:
STD I/O CHANNEL
uart3:
STD I/O CHANNEL
centronics:
STD I/O CHANNEL
net1:
STD I/O CHANNEL
usb1:
See the chapter "Setup Mode"
DEFAULT SETUP
PERFORMED
TRANSFER FILE
USING ZMODEM
TRANSFER
COMPLETED
TRANSFER FILE
USING ZMODEM
Printer rebooted
automatically.
