Intermec EasyCoder PF4i User Manual page 38

Chapter 4—Media Load
Cut-Off , cont.
1
Open the cutter and the side door.
3
If necessary, fold down the edge guide.
Remove any empty core from the media
supply roll post.
30 Intermec EasyCoder PF4i Compact Industrial—User's Guide (Fingerprint)
2
Turn the printhead lift lever clockwise to
raise the printhead.
4
Fit a new roll of media on the supply
post and adjust the edge guide so
the roll becomes fl ush with the center
section.
