Peel-Off , cont.
5
Fit a new roll of labels on the supply
post.
7
Close the edge guide on the supply post.
Route the liner around the tear bar and
the liner drive roller and back under the
print mechanism and guide shaft.
Intermec EasyCoder PF4i Compact Industrial—User's Guide (Fingerprint)
Chapter 4—Media Load
6
Remove labels from the fi rst 50 cm
(20 inches) of the liner. Route the liner
through the print mechanism, push it
inwards, and adjust the edge guides so
the label path becomes fl ush with the
center section.
8
Insert the start of the liner under the lip
of the takeup hub, then rotate the hub
counterclockwise a few turns to wind up
some of the liner.
