Chapter 4—Media Load
Peel-Off , cont.
9
This diagram shows the media and liner
paths.
11
Adjust the position of the green edge
guide so the media is guided with a
minimum of play.
36
Intermec EasyCoder PF4i Compact Industrial—User's Guide (Fingerprint)
10
Turn the printhead lift lever counter-
clockwise to engage the printhead.
12
Close the front and side doors.
