Chapter 4—Media Load
Peel-Off , cont.
1
Open the front and side doors.
3
Pull out the handle to collapse the
takeup hub, then remove any liner.
34 Intermec EasyCoder PF4i Compact Industrial—User's Guide (Fingerprint)
2
Turn the printhead lift lever clockwise to
raise the printhead.
4
If necessary, fold down the edge guide.
Remove any empty core from the media
supply roll post.
