Printhead Replacement, cont.
7
Connect the two cables to the replace-
ment printhead.
9
Turn the printhead lift lever counter-
clockwise so the magnet engages the
printhead bracket.
Intermec EasyCoder PF4i Compact Industrial—User's Guide (Fingerprint)
Chapter 11— Maintenance
8
Put back the printhead in reverse order
and check that the printhead cables run
freely.
10
Load a new supply of media and ribbon,
as described earlier in this manual.
103
