WEP Settings (Cont.)
Default Key:
WEP Keys:
Authentication:
Cancel/Save:
Refer to the Configuring Wireless Network Access section on page 22 and the Using the Site Survey
Tool section on page 23 for further details on these security options.
MVP-5200i Modero® ViewPoint® Touch Panel with Intercom, 5.2 and 5"
Cycles through the four available WEP key identifiers to select a WEP key to
use. As the Default Key value is altered (through selection) the corresponding
"Current Key" is displayed. Each Current Key corresponds to a WEP key.
This feature is useful for accessing different networks without having to
re-enter that networks' WEP key. It is also sometimes used to set up a
rotating key schedule to provide an extra layer of security.
This feature provides another level of security by selecting up to four WEP
Keys.
Push any of the four buttons to open an on-screen keyboard. Both ASCII and
HEX keys are supported. Up to four keys can be configured for both.
• An ASCII key utilizes either 5 or 13 ASCII characters
• A HEX key utilizes either 10 or 26 Hexidecimal characters
Press Done to accept any changes and save the new value.
Note: A 64-bit key will be 10 characters in length while a 128-bit key will be
26 characters in length. The length of the key entered determines the level of
WEP encryption employed (64 or 128-bit). 128-bit keys may be used if
supported by the internal wireless card.
Toggles between the two authentication modes: Open (broadcast publicly) or
Shared (encrypted).
• An Open network allows connections from any client without authentication.
• A Shared network requires the client to submit a key which is shared by the
network AP before it is given permission to associate with the network. In
this case the key is the same as the WEP encryption key.
In either case, if WEP encryption has been enabled, the client will still require
the WEP key to encrypt and decrypt packets in order to communicate with the
network.
• Cancel - discard changes and return to the previous page.
• Save - store the new security information, apply changes, and return to the
previous page.
Protected Setup Pages
