AMX Modero ViewPoint MVP-5200i Operation/Reference Manual page 16

Introduction
The MVP-5200i comes with an integrated rear "kickstand", allowing it to be used and displayed away from a
Charging Station if necessary (FIG. 2). It also comes with a pre-installed 802.11g WPA/WPA2 SDIO wireless
card.
Kickstand
FIG. 2
MVP-5200i side view (with kickstand)
MVP-5200i Specifications
Models Available:
Dimensions:
Weight:
Enclosure:
Power Requirements
(Without Charging):
Power Requirements
(While Charging):
Minimum Power Supply
Required:
2
• MVP-5200i-GB, 5.2" (Gloss Black - FG5966-01)
• MVP-5200i-GB, 5" (Gloss Black - FG5966-03)
• MVP-5200i-GW (Gloss White - FG5966-02)
• MVP-5200i-GW, 5" (Gloss White - FG5966-04)
4 3/4" x 7 9/16" x 13/16" (120.7 mm x 191.8 mm x 20.3 mm)
• Panel: 1.4 lbs ( )
0.64 kg
MVP-5200i-GB: High-gloss black plastic with brushed metal retaining ring.
MVP-5200i-GW: High-gloss white plastic with brushed metal retaining ring.
FG5966-01 & FG5966-02:
Panel with battery fully charged or with no battery:
• Constant current draw: 0.3 A @ 12 VDC
• Startup current draw: 0.4 A @ 12 VDC
FG5966-03 & FG5966-04:
Panel with battery fully charged or with no battery:
• Constant current draw: 0.32 A @ 12 VDC
• Startup current draw: 0.35 A @ 12 VDC
FG5966-01 & FG5966-02:
Panel while charging battery:
• Constant current draw: 1.1 A @ 12 VDC
• Startup current draw: 1.3 A @ 12 VDC
FG5966-03 & FG5966-04:
Panel while charging battery:
• Constant current draw: 1.06 A @ 12 VDC
• Startup current draw: 1.08 A @ 12 VDC
• PS3.0 Power Supply (FG423-30) - All MVP-5200i models are shipped with
this power supply.
MVP-5200i Modero® ViewPoint® Touch Panel with Intercom, 5.2 and 5"
DC power jack
Mini-USB port
