AMX Modero ViewPoint MVP-5200i Operation/Reference Manual page 18

Introduction
MVP-5200i Specifications (Cont.)
External Components
Connector:
DC power port:
Stylus Slot:
Microphone:
Speaker:
Audio Standards:
IR Emitters:
Operating/Storage
Environment
Included Accessories:
Other AMX Equipment:
This device complies with FCC Part 15 and Industry Canada RSS 210 subject to the
following conditions:
1. This device must not cause harmful interference and
2. This device must accept all interference, including interference that interferes with
the operation of this device.
4
5-pin Mini-USB connector used for audio output to USB headphones,
programming, firmware updates, and touch panel file transfer between the PC
and the target panel.
Note: When connecting the panel to PC using a CC-USB (or compatible)
cable, be sure to power the panel On before attempting to connect the USB
cable from the PC to the mini-USB port on the panel.
2.5 mm port to power the panel away from a Charging Station.
Slot where the included stylus is stored, located on the right side of the device.
For use with the intercom feature.
• Frequency: 20 to 160,000 Hz
• S/N Ratio: More than 58 dB
• 4Ohm
• 2 Watts 300Hz cutoff frequency
• G.711 sound standard
• 75dB SPL@1m
Transmit IR over 20 feet (6.10 m) from the panel.
• IR emitters on G4 panels share the device address number of the panel.
• Transmits AMX fixed frequencies at 38KHz and 455KHz and user
programmable frequencies from 20KHz to 1.5MHz
• Operating Temperature: 0° C (32° F) to 40° C (104° F)
• Operating Humidity: 20% - 85% RH
• Storage Temperature: -20° C (-4° F) to 60° C (140° F)
• Storage Humidity: 5% - 85% RH
• MVP-5200i Installation Guide (93-5966-01)
• PS3.0 Power Supply (FG423-30)
• MVP-STYLUS-52 (pre-installed onto the right side of the unit)
(FG5966-06XX)
• MVP-TCS-52 Table Charging Station (FG5966-1X)
• MVP-WCS-52 Wall Charging Station (FG5966-1X)
• CSG-500 Gateway for 50 Users (FG2182-01)
• CSG-544 Gateway for 50 Users, 4 analog phone input ports, 4 PSTN output
ports (FG2182-02)
• CSG-580 Gateway for 50 Users, 8 PSTN Lines (FG2182-03)
• MVP-STYLUS-52 Replacement Stylus, Pack of 3 (FG5966-30-xx)
• CC-USB USB Programming Cable (FG10-5965)
• CC-HPADAPTER Headphone Adapter Cable (FG5966-23)
• NXA-WAP1000 Smart Wireless Access Point (FG2255-51/53)
MVP-5200i Modero® ViewPoint® Touch Panel with Intercom, 5.2 and 5"
