E n t r y C h a n n e l M o d e S w i t c h in g
Figure B-20
Entry Channel Mode v2 Configuration, Remote

ECM Processing

A detailed representation of the sequence of steps that occur between the Hub
units (the channel controller and a switched demodulator), the Remote unit, and
the VMS during the ECM process is shown in figure B-21.
A p p e n d i x B - A u t o m a t i c S w i t c h i n g B-33
