Global mode
146

Controllers: Hand Controllers

Note: Should you accidentally delete some Factory Data, reload
the Backup data or use the Factory Restore procedure (Media >
Utility).
Hide Unknown Files
When this option is checked, non-proprietary files are hidden
when using Media operations, therefore making browsing direc-
tories easier.
Controllers: Hand Controllers
In this page you can program those controls you can operate
with your hands.
Keyboard Settings
Velocity Curve
This parameter sets the sensitivity of the keyboard to your touch.
Fix No dynamic control available. Dynamic values
are fixed, as in a classic organ.
Soft1 ... Hard3
Curves, from the lightest one to the hardest one.
Balance Control
Balance Slider
The BALANCE knob can either be used to mix between the
Keyboard and Accompaniment/Song tracks, or to control the
Accompaniment/Song Volume without changing the Keyboard
tracks. This is always a relative control, whose effective maxi-
mum value is determined by the MASTER VOLUME slider
position.
Note: The BALANCE knob only works in the Style Play and Song
Play modes.
Acc/Song - Kbd Balance
While in Style Play and Song Play mode, the
BALANCE knob balances the volume of the Key-
board (Kbd) tracks against the Style (Accompani-
ment), Song and Pad tracks.
Acc/Song Volume
While in Style Play and Song Play mode, the
BALANCE knob controls the volume of the Style
(Accompaniment), Song and Pad tracks.

Controllers: Foot Controllers

This page lets you select a function to the Assignable Pedal/Foot-
switch, and select the polarity for the Damper and Assignable
Pedal/Footswitch.
The following (optional) Korg pedals are compatible with Pa600:
Type Model
Continuous EXP-2, XVP-10
(Volume/Expression)
Switch PS-1, PS-3
Damper DS-1H (supporting half-pedalling)
Pedal/Footswitch
Function
Function assigned to a continuous (i.e., volume/expression)
pedal, or to a footswitch, connected to the ASSIGNABLE
PEDAL connector. See page 240 for a list of the assignable func-
tions. The first functions are switch-type functions, while the
remaining (starting from Master Volume) are continuous-like
functions.
Calibration
Use this button to calibrate and choose the polarity of the pedal/
footswitch.
Connect the pedal or footswitch to the ASSIGNABLE
1.
PEDAL connector on the back of the instrument.
2. Go to this page, and touch the "Calibration" button in the
display. The following dialog box appears:
You are asked to set the pedal to the maximum value. Press
3.
the footswitch, or press the pedal to the maximum position
(usually front pressed).
