3.3 Diagnostics

Print Config.

Dump Mod e
3.3.1 Print Config.
This feature is used to print current printer configuration to the label. On the
sconfiguration printout, there is a print head test pattern, which is useful for checking if
there is any dot damage on the print head heater element.
Diagnostics
> Print Config.
Dump Mode
Rotate Cutter
Self-test printout
Diagnostics
Rotate Cutter
1/4 Self Test ...
Page 57
Exit
Printing ...
1/1
Print head check pattern
Model name and F/W version
Printed mileage (meter)
Firmware checksum
Serial port configuration
Code page
Country code
Print speed (inch/sec)
Print darkness
Label size (inch)
Gap distance (inch)
Gap/black mark sensor sensitivity
Numbers of download files
Total & available memory space
