4. Thread the ribbon through the ribbon sensor slot and then through the open space
in between print head and platen.
5. Wrap the ribbon onto the ribbon rewind spindle. Keeping the ribbon flat and
without wrinkles.
6. Wind the ribbon clockwise about 3~5 circles onto the ribbon rewind spindle until it
is smooth and properly stretched.
7. Close the print head mechanism making sure the latches are engaged properly.
Page 14 of 73
Ribbon
Ribbon
sensor
