1.3 Safety Precautions
The following sections tell how to make each connection. In most cases,
you will simply need to connect a standard cable. All of the connector
pin assignments are shown in Appendix A.
Warning! Always disconnect the power cord from your chassis
Caution!
1.4 UNO-2059E Series
There are two products in UNO-2059E series listed below:
• UNO-2059E: UNO-2059E hardware platform
• UNO-2059ECE: UNO-2059E hardware platform with Windows CE
OS (built in 128MB CompactFlash card)
• UNO-2059EXP: UNO-2059E hardware platform with WinXPe SP2
(built in 1GB CompactFlash card)
Packing list
Before installing your board, make sure that the following materials
have been received:
UNO-2059E User Manual
whenever you are working on it. Do not connect while
the power is on. A sudden rush of power can damage
sensitive electronic components. Only experienced
electronics personnel should open the chassis.
Always ground yourself to remove any static electric
charge before touching UNO-2041. Modern elec-
tronic devices are very sensitive to static electric
charges. Use a grounding wrist strap at all times.
Place all electronic components on a static-dissipa-
tive surface or in a static-shielded bag.
4
