A.9 6-pin Mini VGA Display Connector (JP3)
VGA Display Connector Pin Assignments
Table A.13: VGA Display Connector Pin Assigns
Pin
1
2
3
4
5
6
VGA Adaptor Cable Pin Assignments
Table A.14: VGA Adaptor Cable Pin Assigns
Pin
1
2
3
4
5
6
7
8
1
2
5
10
15
Signal Name
RED
GREEN
BLUE
NC
GND
GND
GND
GND
P C B
3
4
5
Signal Name
RED
H-SYNC
GREEN
V-SYNC
BLUE
GND
1
6
11
Pin
Signal Name
9
NC
10
GND
11
NC
12
NC
13
H-SYNC
14
V-SYNC
15
NC
29
6
