Chapter 2 Hardware Functionality

The following two figures show the connectors on UNO-2059E. The

following sections give you detail information about function of each

peripheral.

The UNO-2059E offers two RS-232/485 serial communication interface

ports, and they are COM1 and COM2. Each port can be configured indi-

vidually to either RS-232 or RS-485 using on-board jumpers (see Appen-

dix A.2), and Table 2-1 lists the default setting of serial ports.

Table 2.1: COM1 & COM2 Default Settings

COM Port

COM1

COM2

UNO-2059E User Manual

Figure 2.1: UNO-2059E Front Panel

Figure 2.2: UNO-2059E Rear Panel

Default Setting

RS-232
