A.4 Ethernet RJ-45 Connector (LAN1)
Ethernet RJ-45 Connector Pin Assignments
Table A.9: Ethernet RJ-45 Connector Pin Assigns
Pin
1
2
3
4
5
6
7
8
A.5 Phoenix Power Connector (CN1)
Phoenix Power Connector Pin Assignments
Table A.10: Phoenix Power Connector Pin Assigns
Pin
1
2
A.6 5V Power Output Connector (CN2)
This connector is used to output power for a specific device:
• Pin 1: 5V
• Pin 2: GND
Signal Name
18 ~ 48 V
DC
GND
10/100Base-T Signal Name
XMT+
XMT-
RCV+
NC
NC
RCV-
NC
NC
27
Appendix A
