Chapter 1 Overview

1.1 Introduction

Leveraging field-approved and worldwide-awareness real-time OS
technology, Advantech UNO-2000 series provide Windows CE & XPe
SP2 ready solution, and support several standard networking interfaces,
such as Ethernet, Wireless LAN, RS-232/422/485 and so on. Because
of its openness, great expansion capability and reliable design – fanless
and diskless, Advantech UNO-2000 series are ideal embedded plat-
forms to implement custom applications in diversified applications.

1.2 Hardware Specifications

• CPU: AMD Geode GX2-400
• Chipset: AMD CS5535
• BIOS: AWARD 4Mbit FLASH BIOS
• RAM: 256MB DDR RAM on board
• VGA: Supports VGA and VESA
- Display memory: 1 ~ 16 MB share memory, set in BIOS
- CRT display mode: Non-interlaced CRT monitors resolutions up to
1280 x 1024 @ 256 colors or 1024 x 768 @ 24 bpp
- DB-15 and Mini 6-pin VGA connector
Serial Port:Two RS-232/485 ports (COM1 and COM2)
- Controller: Oxford OX16PCI954 UARTs with 128 bytes FIFOs
- IRQ: All ports use the same IRQ assigned by BIOS
- Space reserved for termination resistors
- Automatic RS-485 data flow control
- RS-422/485 surge protection up to 2,000 V
- Data bits: 5, 6, 7, 8
- Stop bits: 1, 1.5, 2
- Parity: none, even, odd
- RS-232 speed: 50 ~ 115.2 Kbps
UNO-2059E User Manual
Two RS-232/422/485 ports (COM3 and COM4)
