Hardware Functionality
This chapter shows how to set up the
UNO-2059E's hardware functions,
including connecting peripherals,
switches and indicators.
Sections include:
• UNO-2059E Peripherals
• COM1&2: RS-232/485 Interfaces
• COM3&4: RS-232/422/485
• LAN: Ethernet Connector
• Power Connector
• LED Indicators
• PS/2 Keyboard and Mouse Connector
• USB1 & USB2
• PCMCIA: PC Card Slot
• VGA: VGA Display Connector
• Programmable LED and Buzzer
• RESET: Reset Button
