Bridging - Zoom Cable Modem/Router User Manual

Table 28. WMM Menu Option
Option
WMM Support
No-Acknowledgement Select On to not transmit acknowledgments for data.
Power Save Support
EDCA AP Parameters
EDCA STA
Parameters

Bridging

The Bridging page allows you to configure WDS (Wireless Distribution System) feature.
Only those bridges listed in the Remote Bridges table will be granted access. APs must
operate in the same channel to be bridged together.
To access the Bridging page:
1
Click Wireless in the menu bar.
2
Then click the Bridging submenu.
Figure 33 shows an example of the menu and Table 29 describes the items you can
Select On to include the WME Information Element in beacon
frame.
Select On to allow the AP (Cable Modem/Router) queuing
packets for stations/clients in power-save mode. Queued
packets are transmitted when the station/client notifies AP that
it has left power-save mode.
Enter the transmit parameters for traffic transmitted from the
AP to the STA (station) for the four Access Categories (AC):
Best Effort (AC_BE), Background (AC_BK), Video (AC_VI)
and Voice (AC_VO). Transmit parameters include Contention
Window (CWmin and CWmax), Arbitration Inter Frame
Spacing Number (AIFSN), and Transmit Opportunity Limit
(TXOP Limit).
There are also two AP-specific settings:

Admission Control: Specify if admission control is
enforced for the Access Categories.

Discard Oldest First. Specify the discard policy for the
queues. On discards the oldest first and Off discards the
newest first.
Specifies the transmit parameters for traffic transmitted from
the STA (station) to the AP for the four Access Categories
(AC): Best Effort (AC_BE), Background (AC_BK), Video
(AC_VI), and Voice (AC_VO). Transmit parameters include
Contention Window (CWmin and CWmax), Arbitration Inter
Frame Spacing Number (AIFSN) and Transmit Opportunity
Limit (TXOP Limit).
97
Description
