Zoom Cable Modem/Router User Manual page 56

To enable a feature:
1
Click the appropriate check box (a check mark will appear).
2
When you are done with your selections, click on the Apply button.
Table 8. Options Menu Option
Option Description
Prevents the Cable Modem/Router or the PCs from responding to
pings to the Cable Modem/Router's WAN IP address or to the
WAN Blocking
devices behind it. This makes it more difficult for hackers to attack
your PCs and other devices on your network.
IPSec/PPTP
Enable to support VPN devices or software on your network.
PassThrough
Allows the Cable Modem/Router to be remotely administered at
Remote
port 8080. When enabled, navigate to http://CMIPAddress:8080/ to
Configuration
administer the Cable Modem/Router remotely). You can find your
Management
CM: WAN IP address on the
Allows multicast specific traffic (denoted by a multicast specific
Multicast
address) to be passed to and from the PCs on the private network
Enable
behind the Cable Modem/Router.
Select Enable to enable the UPnP agent in the Cable
UPnP Enable Modem/Router. If you are running an application that requires
UPnP, check this box.
Allows all LAN hosts to bypass NAT and the Cable Modem/Router's
LAN DHCP Server. Adding MAC addresses into the table is not
Primary
required. If MAC addresses are added to the table then only those
Network
MAC addresses in the list will bypass NAT and the LAN DHCP. All
Bridged
other LAN hosts NOT in the list will use the NAT and LAN DHCP
Server as normal.
The NAT ALG section shows which ALGs (Application Layer
NAT ALG
Gateway) are allowed to pass through the NAT Firewall. Most
Status
users will not need to change these settings.
Basic Setup page.
56
