Zoom Cable Modem/Router User Manual page 103

Table 31. IPSec Menu Option
Option
Tunnel
Name
Local Endpoint
Settings
Address Group Type
Subnet
Mask
Identity Type
Identity
Remote Endpoint
Settings
Address Group Type
Subnet
Mask
Identity Type
Identity
Network Address
Type
Remote Address
Description
This is a pull-down list of VPN Names defined below. Select the
specific VPN tunnel to configure.
Enter a VPN name and click Add New Tunnel.
Configure the local network located at your Cable
Modem/Router's AN side.
Define the local address type. Select IP Subnet to protect the
whole subnet; select Single IP address to protect a single PC or
device; select IP address range to protect several PCs, or
devices.
Enter the subnet scale for address group.
Enter the subnet mask for address group.
Select the type to identify the Cable Modem/Router. The
choices are:WAN IP address, LAN IP address, FQDN (Fully
Qualified Domain Name) or Email address.
Enter the value corresponding to the selected identity type.
Record the parameters of the network on which the peer VPN is
located.
Define the local address type. Select IP Subnet to protect the
whole subnet; select Single IP address to protect a single PC;
select IP address range to protect several PCs.
Enter the subnet for address group.
Enter the subnet mask for address group.
Select the type to identify the Cable Modem/Router. The
choices are WAN IP address, IP address, FQDN or Email
address.
Enter the value corresponding to the selected identity type.
Enter the IP address or domain name of the peer VPN Cable
Modem/Router. You can select IP address, which is typically
suitable for static public IP addresses or FQDN, which is
typically suitable for dynamic public IP address.
Enter IP address according to the Network Address Type.
