Zoom Cable Modem/Router User Manual page 87

WPA2-PSK
WPA/WPA2 Encryption
WPA Pre-Shared Key
RADIUS Server
RADIUS Port
(Relevant only when the
RADIUS server is enabled)
RADIUS Key
(Relevant only when the
RADIUS server is enabled)
Group Key Rotation
Interval
(Relevant only when the
RADIUS server is enabled)
WPA/WPA2 Re-auth
Interval
WEP Encryption
Shared Key
Authentication
802.1x Authentication
(only available when WEP
is enabled)
Network Key 1-4
Current Network Key
PassPhase
Offers state-of-the-art security. When enabled, you must
also enter a Pre-Shared Key below that will by used by all
wireless clients to access the wireless network.
Select Enable to use WPA/WPA2 encryption. Most users
should use the default setting of TKIP+AES.
Enter a 8-63 ASCII character string if you have enabled
WPA-PSK or WPA2-PSK.
If you're using a RADIUS server, enter it's IP address
here. The RADIUS server may be on either public network
(WAN) or private network (LAN).
Enter the UDP port number of the RADIUS server. The
default port is 1812.
Enter the RADIUS Key.
When enabled, the Cable Modem/Router generates the
best possible random group key and updates all
key-management capable clients periodically. Set to zero
to disable periodic rekeying.
Interval (in seconds) at which the Cable Modem/Router (if
using WPA-PSK key management) or RADIUS server (if
using WPA key management) sends a new group key out
to all clients. The re-keying process is the WPA equivalent
of automatically changing the WEP key for an AP and all
stations in a WLAN on a periodic basis.
WEP Encryption can be set to WEP 128-bit, 64-bit, or
Disable. Both the wireless clients and the Cable
Modem/Router must use the same WEP key.
Select Enable to enable. Shared Key authentication is only
available when WEP is enabled.
Select Enable to enable 802.1x authentication. Enable
802.1x Authentication only if you have a RADIUS server.
Most users will leave this disabled.
You can pre-define up to 4 keys for 64-bit or 128-bit WEP.
64-bit keys require 10 hexadecimal digits and 128-bit key
require 26 hexadecimal digits.
Select one of the four pre-defined keys as the current
network key.
Enter a word or group of printable characters and click
Generate WEP keys to generate WEP encryption key.
These characters are case sensitive.
87
