4.1.3 Identifying the VoIP Intercom Connectors
See the following Figures and Tables to identify the connectors and functions.
.
Connector
J2
J5
J6
Operations Guide
Figure 4-3. J2, J5, and J6 Connector Locations
Table 4-2. Connector Functions
Function
Call Button. LED Interface
Microphone Interface
Speaker Interface
930242L
Installing the VoIP Intercom
Intercom Setup
CyberData Corporation
11
