2.1.3 Identifying the VoIP Intercom Connectors

See the following Figures and Tables to identify the connectors and functions.
.
Operations Guide
Figure 2-3. J2, J5, and J6 Connector Locations
Table 2-2. Connector Functions
Connector
J2 Call Button. LED Interface
J5 Microphone Interface
J6 Speaker Interface
930242A-D
Installing the VoIP Intercom
Function
CyberData Corporation
13
Intercom Setup
