Installing the VoIP Indoor Intercom
9
Intercom Setup

2.2.3 Identifying the VoIP Intercom Connectors

See
Figure
2-6,
Figure
2-7, and
Table 2-2
to identify the connectors and functions.
Figure 2-6. J2, J5, and J6 Connector Locations
Figure 2-7. J1 and J7 Connector Locations
Operations Guide
930260A
CyberData Corporation
