4.1.5 Network Connectivity, and Data Rate

When you plug in the Ethernet cable or power supply:
• The square, green Link light above the Ethernet port indicates that the network connection has
been established (see
auto-negotiated baud rate:
• This light is yellow at 10 Mbps.
• It is orange at 100 Mbps.
Operations Guide
Figure 4-6 and Figure
Figure 4-6. Network Connector Prior to Installation
930242L
4-7). The Link light changes color to confirm the
Installing the VoIP Intercom
Intercom Setup
Ethernet
Link
Activity
